Galvanized Steel Rigid Conduit IMC Pipe Electrical Metal Conduit with UL Certificated

Weifang East Pipe Industry Technical Co., Ltd.
  • Color：Silver Grey
  • IP Rating：IP66
  • Surface Treatment：Galvanised
  • Application：Building
  • Material：Carbon Steel
  • Certification：UL

Base Info

  • Usage：Wire and Cable Protection
  • Thickness：0.104 - 0.266 Inch
  • Outer Diameter：0.84 - 6.625 Inch
  • Technique：Cold Rolled
  • Length：3050mm
  • Capacity：5000 Ton,Tons Per Month
  • Transport Package：Woodpackage
  • Specification：1,2” to 6” inch
  • Trademark：eaststeelpipe
  • Origin：China
  • HS Code：73063090
  • Production Capacity：5000 Ton,Tons Per Month

Description

Trade SizeNominal Wt. per 100Ft(30.5M)Nominal Outside DiameterNominal Wall ThicknessU.S.MetricLbsKgIn.mmIn.mm1/2"168237.20.8421.30.1042.63/4"2110949.441.0526.70.1072.71"2716173.031.31533.40.1263.21-1/4"3521898.881.6642.20.1333.41-1/2"41263119.31.948.30.1383.52"53350158.762.37560.30.1463.72-1/2"63559253.562.875730.1934.93"78727329.773.588.90.2055.23-1/2"91880399.174101.60.2155.54"1031030467.214.5114.30.2255.75"1291400635.045.563141.30.2456.26"1551840834.626.625168.30.2666.8



Applicable tolerances:

Length: 10Ft (3.05m) ± ¼" (±6.35mm).

Outside Diameter: ½"-2" ±0.015" (±0.38mm); 2½"-4" ±0.025" (±0.64mm); 5"-6" ± 1%
