Hot Sell Pg/Metric/NPT Thread IP68 Brass Metal Waterproof Cable Gland
Guangzhou Golden Electric Co., Ltd- Certification：CCC, RoHS, ISO, CE
- Surface Treatment：Electroplating
- Color：Metallic Color
- IP Rating：IP68
- Material：Brass Nickel Plated
- Type：Straight Head
Base Info
- Model NO.：E-15 SERIES
- Clamping Insert：Nylon PA
- Working Temperature：-40~100
- Advantages：Fast Delivery
- Size：M10-M100
- Model Number：M10-M100
- Key Words：Brass Cable Gland
- Function：Cable Protection
- Hot Searching：Atex Cable Gland
- Samples：Provide Sample
- Feature：Seal Part Hold Cable Firmly
- MOQ：100PCS
- Work Temperature：40~+100
- Cable Gland：Waterproof
- Thread Length：Standard & Customization
- Other Size：Customization
- Transport Package：Standard Export Carton
- Specification：Metric , PG , G , NPT
- Trademark：Golden Electric
- Origin：China
- HS Code：33039649
- Production Capacity：50000PCS,Month
Description
EMC Cable Gland ---D series,Metric threadProduct Code Thread AG Cable range(mm) Thread diameter(mm) Board caliber(mm) Thread length GL(mm) Joint length(mm) Wrench diameter (mm) JX-D.M12-EMC M12*1.5 6.5-3 12 12-12.2 7 19 14 JX-D.M14-EMC M14*1.5 8-4 14 14-14.2 7 19 17 JX-D.M16-EMC M16*1.5 8-4 16 16-16.2 8 20 18 JX-D.M18-EMC M18*1.5 10-5 18 18-18.2 8 21 20 JX-D.M20-EMC M20*1.5 12-6 20 20-20.2 8 22 22 JX-D.M22-EMC M22*1.5 14-10 22 22-22.2 8 23 24 JX-D.M24-EMC M24*1.5 14-10 24 24-24.2 9 25 24/27 JX-D.M25A-EMC M25*1.5 14-10 25 25-25.2 9 25 24/27 JX-D.M25B-EMC M25*1.5 18-13 25 25-25.2 9 27 30/27 JX-D.M27A-EMC M27*1.5 18-13 27 27-27.2 9 27 30 JX-D.M27B-EMC M27*2 18-13 27 27-27.2 9 27 30 JX-D.M28A-EMC M28*1.5 18-13 28 28-28.2 9 27 30 JX-D.M28B-EMC M28*2 18-13 28 28-28.2 9 27 30 JX-D.M30A-EMC M30*1.5 18-13 30 30-30.2 9 29 30/32 JX-D.M30B-EMC M30*2 18-13 30 30-30.2 9 29 30/32 JX-D.M32A-EMC M32*1.5 22-15 32 32-32.2 10 29 35 JX-D.M32B-EMC M32*2 22-15 32 32-32.2 10 29 35 JX-D.M33A-EMC M33*1.5 22-15 33 33-33.2 10 29 35 JX-D.M33B-EMC M33*2 22-15 33 33-33.2 10 29 35 JX-D.M36A-EMC M36*1.5 25-18 36 36-36.2 10 31 40 JX-D.M36B-EMC M36*2 25-18 36 36-36.2 10 31 40 JX-D.M37A-EMC M37*1.5 25-18 37 37-37.2 10 31 40 JX-D.M37B-EMC M37*2 25-18 37 37-37.2 10 31 40 JX-D.M40A-EMC M40*1.5 25-18 40 40-40.2 11 31 40/45 JX-D.M40B-EMC M40*2 25-18 40 40-40.2 11 31 40/45 JX-D.M40C-EMC M40*1.5 30-22 40 40-40.2 11 35 45 JX-D.M40D-EMC M40*2 30-22 40 40-40.2 11 35 45 JX-D.M42A-EMC M42*1.5 30-22 42 42-42.2 11 35 45 JX-D.M42B-EMC M42*2 30-22 42 42-42.2 11 35 45 JX-D.M47A-EMC M47*1.5 33-25 47 47-47.2 11 37 50 JX-D.M47B-EMC M47*2 33-25 47 47-47.2 11 37 50 JX-D.M48A-EMC M48*1.5 33-25 48 48-48.2 11 37 50/52 JX-D.M48B-EMC M48*2 33-25 48 48-48.2 11 37 50/52 JX-D.M50A-EMC M50*1.5 38-32 50 50-50.2 12 37 50/55 JX-D.M50B-EMC M50*2 38-32 50 50-50.2 12 37 50/55 JX-D.M54A-EMC M54*1.5 38-32 54 54-54.2 12 38 57 JX-D.M54B-EMC M54*2 38-32 54 54-54.2 12 38 57 JX-D.M56A-EMC M56*1.5 38-32 56 56-56.2 12 38 57/59 JX-D.M56B-EMC M56*2 38-32 56 56-56.2 12 38 57/59 JX-D.M60A-EMC M60*1.5 44-37 60 60-60.2 13 38 64 JX-D.M60B-EMC M60*2 44-37 60 60-60.2 13 38 64 JX-D.M63A-EMC M63*1.5 44-37 63 63-63.2 13 38 64/68 JX-D.M63B-EMC M63*2 44-37 63 63-63.2 13 38 64/68 JX-D.M64A-EMC M64*1.5 44-37 64 64-64.2 13 38 64/68 JX-D.M64B-EMC M64*2 44-37 64 64-64.2 13 38 64/68 JX-D.M72-EMC M72*2 52-42 72 72-72.2 15 42 65/68 JX-D.M75-EMC M75*2 52-42 75 75-75.2 15 42 78 JX-D.M80-EMC M80*2 62-50 80 80-80.2 15 45 86/88 JX-D.M88-EMC M88*2 70-60 88 88-88.2 15 45 98 JX-D.M100-EMC M100*2 80-70 100 100-100.2 15 45 110
Field of Application
- Golden has been granted ISO9001 management system certifications. The comprehensive product line has more than 1000 models which have been approved by TUV,CE,CQC,SGS,ROHS,SASO. The productsells well to UK, Spain, Portugal, Singapore, Turkey, Russia, Korea, South Africa... more than 60 countries and regions.
- Golden is always striving hard to provide the best services and competitive price to all customers.
Packing&Delivery
packing can be supplied according customers request.
Delivery Detail:
Shipped in 7 days after payment
Related Products
RFQ
Q1. What are your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered a patent,
we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What are your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q3. What are your terms of delivery?
A: EXW, FOB.
Q4. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Field of Application
Cable glands are mechanical cable entry devices. They are used throughout a number of industries in conjunction with cable and wiring used in elelctrical instrumentation and automation systems.
Cable gland may be used on all types of electrical power, control, instrumentation, data and telecommunications cables. They are used as a sealing and termination device to ensure that the charachteristcs of the enclosure which the cable enters can be maintained adequately.
About US
- Golden has been granted ISO9001 management system certifications. The comprehensive product line has more than 1000 models which have been approved by TUV,CE,CQC,SGS,ROHS,SASO. The productsells well to UK, Spain, Portugal, Singapore, Turkey, Russia, Korea, South Africa... more than 60 countries and regions.
- Golden is always striving hard to provide the best services and competitive price to all customers.
Packing&Delivery
Packaging Details:
Customized Packing: Header card packing, Blister with card packing, Double blister packing, Canister packing, otherpacking can be supplied according customers request.
Delivery Detail:
Shipped in 7 days after payment
