• Model NO.：NXJ
• Structure：G Clamp
• High Quality Str：Blot Type Strain Clamp
• Transport Package：Export Standard Package
• Specification：ISO9001: 2008
• Trademark：L&R or according to customer′s requirement
• Origin：Wenzhou, Zhejiang
• Production Capacity：10, 000PCS,Month
• Package size per unit product：30.00cm * 30.00cm * 30.00cm
• Gross weight per unit product：2.000kg

Basic Info.

Model NO. NXJ Structure G Clamp High Quality Str Blot Type Strain Clamp Transport Package Export Standard Package Specification ISO9001: 2008 Trademark L&R or according to customer′s requirement Origin Wenzhou, Zhejiang Production Capacity 10, 000PCS/Month

Packaging & Delivery

Package size per unit product 30.00cm * 30.00cm * 30.00cm Gross weight per unit product 2.000kg

Product Description

Application
NXJ Series is suitable for strain clamp insulation string of 10kV aerial insulation aluminium core wire JKLYJ terminal or two ends fixing and tighten aerial insulation
Structure feature
1. The shell made of anti-oxidate high strength aluminum alloy.
2. The core of wedge made of insulating reinforce plastics, withstand voltage : ≥18kV not breakdown one min.
3. Not remove the insulation layer,AI-core wire are current use.
4. Without waste power
5. Wedge structure

Good grip, fixed-line firm;
Energy-saving design, the line loss is small;
Good insulation, not to hurt the wire;
Easy to install, simple to maintain;

Performance:

The clamp has designed four core parallel groove, after clamping the four insulation conductor ( not remove the insulation layer) tighten up the bolt, have large grip strength.

Catalog No.	Applicable conductor (mm²)	Grip strength (KN)
NXJ-1A	16-50	11.7
NXJ-2A	70-120	17.3
NXJ-1B	25-50	11.7
NXJ-2B	70-120	17.3
NXJ-3B	150-185	22.5

Our products have being service in more than 20 countries power system, we focus on Eelectric power more than 20 years.
Hope we can establish a good business relationship in the future. we will supply professional technology and good service to you in the first time.
