4 Cores Fiber Optic Terminal Box Without Pigtails and Adapters

Takfly Communications Co., Ltd.
  • Certification：CCC, RoHS, ISO, CE
  • Port Number：<8
  • Usage：Audio, Coaxial Cable, Fiber, STP, UTP
  • Type：IDF
  • Working Temperature：-40 to +85
  • Relative Humidity：≤ 85%

Base Info

  • Model NO.：FTKS-1805-04A
  • Atmospheric Pressure：70kpa to 106kpa
  • Insert Loss：≤ 0.2dB
  • Upc Return Loss：≥ 50dB
  • APC Return Loss：≥ 60dB
  • Insert and Pull out Life：≥ 1000 Times
  • Insulation：IR ≥1000m Ω,500V (Direct Current)
  • Fiber Cores：4
  • Item Model：Ftks-1805-04A
  • Transport Package：Carton Box
  • Specification：186 * 116 * 41mm
  • Trademark：Takfly
  • Origin：Shenzhen China
  • HS Code：8517622990
  • Production Capacity：100000PCS,Month

Description

Work Temperature

-40 C ~+85 C

Relative Humidity

≤ 85% (+30 C)

Atmospheric Pressure

70Kpa~106Kpa

Insert Loss

≤ 0.2dB

UPC Return Loss

≥ 50dB

APC Return Loss

≥ 60dB

Insert and Pull out Life

≥ 1000 times

Insulation

The grounding device is insulated with the   Termination box, IR ≥1000m Ω/500V (direct current)

Withstand Voltage

Between the grounding device and the box   body, the withstand voltage is over 3000V/Min, no

breakdown and flashover. U ≥3000V   (direct current)


OUR CERTIFICATE & WORLDWIDE EXHIBITION
