Wiring Harness Insulation Polyolefin Heat Shrink Sleeve
GUANGZHOU KAIHENG SPECIAL WIRE&CABLE CO., LTD.- Certification：UL, RoHS, ISO
- Color：Black
- IP Rating：IP68
- Usage：Lighting Decoration, Earphone Line, Electric Wire, DVI Line, HDMI Cable
- Material：PE
- Type：High Temperature Resistance
Base Info
- Model NO.：k-2hf
- Transport Package：Cartons
- Specification：1.0mm-50mm
- Origin：China
- Production Capacity：500000000year
Description
Product Description
Standard length (m/spool)Inside diameter Wall thickness Inside diameter(max.) Wall thickness(min.) Φ0.8 1.0±0.2 0.15±0.05 0.50 0.25 200 Φ1.0 1.5±0.3 0.20±0.05 0.60 0.33 200 Φ1.5 2.0±0.3 0.20±0.05 0.75 0.36 200 Φ2.0 2.5±0.3 0.20±0.05 1.00 0.44 200 Φ2.5 3.0±0.3 0.25±0.05 1.25 0.44 200 Φ3.0 3.5±0.3 0.25±0.05 1.50 0.44 200 Φ3.5 4.0±0.3 0.25±0.05 1.75 0.44 200 Φ4.0 4.5±0.3 0.25±0.05 2.00 0.44 200 Φ4.5 5.0±0.3 0.25±0.05 2.25 0.44 200 Φ5.0 5.5±0.3 0.28±0.05 2.50 0.56 100 Φ6.0 6.5±0.3 0.28±0.05 3.00 0.56 100 Φ7.0 7.6±0.3 0.30±0.07 3.50 0.56 100 Φ8.0 8.6±0.3 0.30±0.07 4.00 0.56 100 Φ9.0 9.6±0.3 0.30±0.07 4.50 0.56 100 Φ10.0 10.7±0.4 0.30±0.07 5.00 0.56 100 Φ11.0 11.7±0.4 0.30±0.07 5.50 0.56 100 Φ12.0 12.7±0.4 0.30±0.07 6.00 0.56 100 Φ13.0 13.7±0.4 0.35±0.08 6.50 0.69 100 Φ14.0 14.7±0.4 0.35±0.08 7.00 0.69 100 Φ15.0 15.7±0.5 0.35±0.08 7.50 0.69 100 Φ16.0 16.7±0.5 0.35±0.08 8.00 0.69 100 Φ18.0 19.0±0.5 0.40±0.10 9.00 0.77 100 Φ20.0 21.0±0.5 0.40±0.10 10.00 0.77 50 Φ22.0 23.0±0.5 0.40±0.10 11.00 0.77 50 Φ25.0 26.0±1.0 0.45±0.10 12.50 0.87 50 Φ28.0 29.0±1.0 0.45±0.10 14.00 0.87 50 Φ30.0 31.5±1.0 0.45±0.10 15.00 0.87 50 Φ35.0 36.5±1.0 0.50±0.10 17.50 0.97 50 Φ40.0 41.5±1.0 0.50±0.10 20.00 0.97 50 Φ50.0 51.5±1.0 0.55±0.10 25.00 0.97 50 Φ60.0 63.0±3.0 0.60±0.15 30.00 1.17 25 Φ70.0 71.0±3.0 0.60±0.15 35.00 1.17 25 Φ80.0 81.0±3.0 0.65±0.15 40.00 1.20 25 Φ90.0 91.0±3.0 0.75±0.15 45.00 1.30 25 Φ100 101.0±3.0 0.75±0.15 50.0 1.30 25 Φ120 121.0±4.0 0.80±0.20 60.0 1.40 15 Φ150 151.0±4.0 0.80±0.20 75.0 1.50 15 Φ180 181.0±4.0 0.85±0.20 90.0 1.60 15
Color Standard packagingStandard: Black (-BK), white (-WH) On spools. Cut pieces are available upon request.
Nonstandard: Available upon request.
Nonstandard size Ordering description
Special sizes are available upon request Specify product type, size (mm or inch) and color.
Our Company
FAQ
Q1. What is your terms of packing?
A: Generally, we pack our goods in KOSOO standard paper rolls and cartons. If you have special request,we could do the OEM packing for you.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF
Q4. How about your delivery time?
A: Generally, it will take 20-30 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the courier cost.
Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
