Silicon Rubber Metric Type Waterproof Adjustable Brass Cables Gland Connector Brass Metal Nickel Glands M27
Yueqing Jixiang Connector Co., Ltd.- Certification：CCC, RoHS, ISO, CE, IP68
- Surface Treatment：Electroplating
- Color：Metallic Color
- IP Rating：IP68
- Material：Brass
- Type：Straight Head
Base Info
- Model NO.：PG7-PG21 M12-M30, G, NPT
- Factory Report：ISO90001
- Thread Type：Metric
- Claw：Silicon Rubber
- Sealing Ring：Silicon Rubber
- Working Temperature：-60 to 250
- Transport Package：Standard Export Carton
- Specification：Customization
- Trademark：JXLJQ
- Origin：China Mainland
- HS Code：8547901000
- Production Capacity：3000000PCS,Month
Description
Metal Cable Gland - Silicone Series
Product Code
Thread AG
Applicable cable range(mm)
Thread O.D.(mm)
Mounting Hole Diameter(mm)
Thread length GL(mm)
Joint length H(mm)
Spanner Size (mm)
JX-M8-Sl
M8*1
5.5-2
8
8-8.2
5
16
12
JX-M12A-Sl
M12*1
6.5-3
12
12-12.2
7
19
14
JX-M12B-Sl
M12*1.25
8-3
12
12-12.2
7
16
16
JX-M12C-Sl
M12*1.5
8-3
12
12-12.2
7
16
16
JX-M14-Sl
M14*1.5
8-3
14
14-14.2
7
16
16
JX-M16-Sl
M16*1.5
9-4
16
16-16.2
8
20
20/18
JX-M18-Sl
M18*1.5
10-5
18
18-18.2
8
20
20
