Flame Retardant Self Closing Woven Wrap Cable Sleeving Sheath for Home Office
Xiamen QX Trade Co., Ltd.- Certification：CSA, UL, RoHS, ISO, Halogen Free
- Color：Black
- IP Rating：IP65
- Usage：High-Speed Rail,Auto,Automation Equipment
- Material：Polyester Mutifilament and Monofilament
- Type：Spiral Wrapping
Base Info
- Model NO.：BS-WS
- Classification：Side Entry Sleeve
- Flame Retardant：High
- Abrasion Resistance：Medium
- Condition：New
- Customized：Non-Customized
- Flame Rating：UL94V0,DIN5510,BS6853
- Wall Thickness：0.027"
- Tensile Strength - Yarn (ASTM D-2265) Lb：7.5
- Available Size：5mm ID~50mm ID
- Standard Color：Black,White
- Flammability：V-0
- Feature：Protect and Route Cables with a Soft
- Color Range：Black ,White ,Grey, Blue, Orange,Yellow,Customized
- Transport Package：25m,Roll
- Specification：16mm
- Trademark：EKO
- Origin：Fujian, China
- HS Code：630790009
- Production Capacity：3000000 M,Month
Description
Black
White
Grey100m/roll BS-WS008 8.0 9.0 100m/roll BS-WS010 10.0 11.0 100m/roll BS-WS013 13.0 14.0 50m/roll BS-WS016 16.0 17.0 50m/roll BS-WS019 19.0 20.0 25m/roll BS-WS025 25.0 27.0 25m/roll BS-WS029 29.0 31.0 25m/roll BS-WS032 32.0 34.0 25m/roll BS-WS038 38.0 40.0 25m/roll BS-WS050 50.0 52.0 25m/roll
Product feature
White
Grey
Product feature
| Material | Polyester monofilament+Polyester multifilament |
| Continuoos working temperature | -50~+150ºC |
| Melt point | 240+(-)10ºC |
| Flame rating | UL94 V0,DIN5510,BS6853 |
| Thickness | 0.7mm(0.027") |
| Abrasion resistance | Medium |
| Specific gravity | 1.38 |
| Standard color | Black,White,Grey |
| Certificated | ROHS,Halogen Free |
| Cutting tool | Hot Knife |
