IP68 Brass Through Cable Gland RoHS M16*1.5 Metal Cable Joints
Yueqing Jixiang Connector Co., Ltd.- Certification：RoHS, ISO, CE
- Surface Treatment：Electroplating
- Color：Metallic
- IP Rating：IP68
- Material：Brass
- Type：Straight Head
Base Info
- Model NO.：M16*1.5
- Claw：PA
- Sealing and Sealing Ring：NBR
- Work Temperature：-40~100, Short Time to 120
- Advantage：Customization Service Is Available
- Transport Package：Standard Export Carton
- Specification：PG7-PG63
- Trademark：JXLJQ
- Origin：Zhejiang, China
- HS Code：8547901000
- Production Capacity：100000PCS,Week
Description
Overview
Product DescriptionItem Name Through type waterproof brass cable gland Material Brass with nickel plated Approvals ISO9000,TUV,IP68 Working temprrature Through type waterproof brass cable gland Thread AG Cable range(mm) Thread O.D(mm) Mounting hole diameter(mm) Thread length GL(mm) Spanner size(mm) PG7 6.5-3 12.5 12.5-12.7 7 14 PG9 8-4 15.2 15.2-15.4 8 17 PG11 10-5 18.6 18.6-18.8 8 20/21 PG13.5 12-6 20.4 20.4-20.6 8 22 PG16 14-10 22.5 22.5-22.7 9 24 PG21 18-13 28.3 28.3-28.5 9 30 PG25 22-15 32 32-32.2 10 35 PG29 25-18 37 37-37.2 11 40 PG36 33-25 47 47-47.2 12 50 PG42 38-32 54 54-54.2 13 57 PG48 44-37 59.3 59.3-59.5 14 64 PG63 52-42 72 72-72.2 15 78
Q: Are you trading company or manufacture?
A: We are manufacturer and have focus on cable glands for over 10 years.
Our advantage are lower prices and the ability to provide customized services compared to trading companies.
Q: What about the lead time for mass production?
A: Your goods can be delivered in 3-7 days if it is the standard models and in stock.
For special model or large order, you can negotiate the delivery date with us.
Q: Can you provide the free samples?
A: Yes, we can offer the samples for free charge, meanwhile, the cost of freight is on your account.
Q: Can I have a visit to your factory before the order?
A: Yes, welcome to our factory! You also can visit our factory by video for inconvenient time.
