Brass Cable Gland Pg 21 Non Armored Connectors

Yueqing Jixiang Connector Co., Ltd.
  • Certification：RoHS, ISO, CE, Reach
  • Surface Treatment：Electroplating
  • Color：Metallic Color
  • IP Rating：IP68
  • Material：Brass
  • Type：Straight Head

Base Info

  • Model NO.：PG21 (13-18mm)
  • Transport Package：,
  • Specification：M8-M120 , PG7-PG63 , NPT1,4-NPT3; G1,4-G3
  • Trademark：JXLJQ
  • Origin：Zhejiang Province, China
  • HS Code：33039649
  • Production Capacity：5000 PCS,Week

Description

Product Name:Waterproof cable glandMain material:Nickel-plated brassStandard size:M8-M120; PG7-PG63; NPT1/4-NPT3; G1/4 -G3Certification:RoHS, CE, TUV, IP68, ISO9001Notes:Customization service is available
Brass Cable Gland Pg 21 Non Armored ConnectorsSizesCable Range(mm)Thread O.D.(mm)Thread Length(mm)Spanner Size(mm)M8x12-58512M10x13-6.510714M12x1.53-6.512714M14x1.54-814717M16x1.54-816818M18x1.55-1018820M20x1.56-1220822cM24x1.510-1424924/27M28x1.513-1828930M32x1.515-22321035.........................M100x270-8010015110PG73-6.512.5714PG94-815.2818PG115-1018.6820/21PG13.56-1220.4822PG1610-1422.5924PG2113-1828.3930/32.........................PG6342-52721578NPT1/43-6.513.6714NPT3/84-817818NPT1/26-1221.2822NPT3/413-1826.5930NPT118-2533.21140.........................NPT365-7088.61598G1/43-6.513.1714G3/84-816.6818G1/26-1220.9822G3/413-1826.4930G118-2533.21140.........................G365-7087.81594

More size information, kindly contact us directly.. We provide customization service !

Brass Cable Gland Pg 21 Non Armored ConnectorsCable gland packing Details: Poly bag with label + Standard export carton with label.
Delivery Details: Normally 7 working days after received the payment.
Brass Cable Gland Pg 21 Non Armored ConnectorsBrass Cable Gland Pg 21 Non Armored Connectors                                                                                    Company ShowBrass Cable Gland Pg 21 Non Armored ConnectorsBrass Cable Gland Pg 21 Non Armored Connectors

YUEQING JIXIANG CONNECTOR CO.,LTD

We're a professional manufacturer of various kinds of cable glands and cable connectors. JIXIANG combines research,
production and sales. The main products are metal cable glands and nylon cable glands.
We firmly believe that market is the key to the development of enterprises.
Thus, we always take the high quality as our essential principle.Our products are approved by CE, IP68, ROHS, EX ATEX, TUV and ISO9000.
It was widely used in electronic, machinery, instrument, electrical appliances and other industrial fields.Brass Cable Gland Pg 21 Non Armored ConnectorsBrass Cable Gland Pg 21 Non Armored Connectors
