- Model NO.:PG,Metric,NPT
- Thread Type:Pg, Metric, G, and NPT Thread
- Materials:UL Approved Nylon PA66
- Temperature:-40 ~100 Degree
- Features:Claws and Seals of Excellent Design
- Nylon:PA66 UL Approved
- Transport Package:Standard Export Packing
- Specification:UL
- Trademark:Linkwell Electric
- Origin:Shanghai, China
- HS Code:73079900
- Production Capacity:100, 000 Pieces Per Month
PG Type | Thread Size | Applicable to cable Range mm | Thread diameter O.D. L2(mm) | Thread length L1( mm) | Spanner Size |
PG7-M | PG7 | 3~6.5 | 12.5 | 5 | 14 |
PG7-M | PG7 | 2~5 | 12.5 | 5 | 14 |
PG9-M | PG9 | 5~9 | 15.2 | 6 | 17 |
PG9-M | PG9 | 2~6 | 15.2 | 6 | 17 |
PG11-M | PG16 | 6.5~11 | 18.6 | 6 | 20 |
PG11-M | PG19 | 3~7 | 18.6 | 6 | 20 |
PG13.5-M | PG36 | 7~13 | 20.4 | 6.5 | 22 |
PG13.5-M | PG63 | 5~9 | 20.4 | 6.5 | 22 |
PG16-M | PG16 | 9~14 | 22.5 | 6.5 | 24 |
PG16-M | PG16 | 6~12 | 22.5 | 6.5 | 24 |
PG21-M | PG21 | 11~18 | 28.3 | 7 | 30 |
PG21-M | PG21 | 9~16 | 28.3 | 7 | 30 |
PG29-M | PG29 | 18~26 | 37 | 8 | 40 |
PG29-M | PG29 | 13~20 | 37 | 8 | 40 |
PG36-M | PG36 | 24~33 | 47 | 9 | 50 |
PG36-M | PG36 | 20~26 | 47 | 9 | 50 |
PG42-M | PG42 | 30~39 | 54 | 10 | 58 |
PG42-M | PG42 | 25~31 | 54 | 10 | 58 |
PG48-M | PG48 | 34~45 | 59.3 | 10 | 63 |
PG48-M | PG48 | 29~35 | 59.3 | 10 | 63 |
Metallic cable gland PG-LMPG Type | Thread Size | Applicable to cable Range mm | Thread diameter O.D. L2(mm) | Thread length L1( mm) | Spanner Size |
PG7-LM | PG7 | 3~6.5 | 12.5 | 10 | 14 |
PG7-LM | PG7 | 2~5 | 12.5 | 10 | 14 |
PG9-LM | PG9 | 5~9 | 15.2 | 10 | 17 |
PG9-LM | PG9 | 2~6 | 15.2 | 10 | 17 |
PG11-LM | PG16 | 6.5~11 | 18.6 | 10 | 20 |
PG11-LM | PG19 | 3~7 | 18.6 | 10 | 20 |
PG13.5-LM | PG36 | 7~13 | 20.4 | 10 | 22 |
PG13.5-LM | PG63 | 5~9 | 20.4 | 10 | 22 |
PG16-LM | PG16 | 9~14 | 22.5 | 10 | 24 |
PG16-LM | PG16 | 6~12 | 22.5 | 10 | 24 |
PG21-LM | PG21 | 11~18 | 28.3 | 12 | 30 |
PG21-LM | PG21 | 9~16 | 28.3 | 12 | 30 |
PG29-LM | PG29 | 18~26 | 37 | 12 | 40 |
PG29-LM | PG29 | 13~20 | 37 | 12 | 40 |
PG36-LM | PG36 | 24~33 | 47 | 15 | 50 |
PG36-LM | PG36 | 20~26 | 47 | 15 | 50 |
PG42-LM | PG42 | 30~39 | 54 | 15 | 58 |
PG42-LM | PG42 | 25~31 | 54 | 15 | 58 |
PG48-LM | PG48 | 34~45 | 59.3 | 15 | 63 |
PG48-LM | PG48 | 29~35 | 59.3 | 15 | 63 |
Metallic Cable gland PG-MA type brass cable glandPG Type | Thread Size | Applicable to cable Range mm | Thread diameter O.D. L2(mm) | Thread length L1( mm) | Spanner Size |
PG7-MA | PG7 | 3~6.5 | 12.5 | 6 | 14 |
PG7-MA | PG7 | 2~5 | 12.5 | 6 | 14 |
PG9-MA | PG9 | 4~8 | 15.2 | 7 | 18 |
PG9-MA | PG9 | 2~6 | 15.2 | 7 | 18 |
PG11-MA | PG16 | 5~10 | 18.6 | 7 | 20 |
PG11-MA | PG19 | 3~7 | 18.6 | 7 | 20 |
PG13.5-MA | PG36 | 6~12 | 20.4 | 7.5 | 22 |
PG13.5-MA | PG63 | 5~9 | 20.4 | 7.5 | 22 |
PG16-MA | PG16 | 9~14 | 22.5 | 7.5 | 24 |
PG16-MA | PG16 | 6~12 | 22.5 | 7.5 | 24 |
PG21-MA | PG21 | 13~18 | 28.3 | 8 | 30 |
PG21-MA | PG21 | 9~16 | 28.3 | 8 | 30 |
PG29-MA | PG29 | 18~25 | 37 | 9 | 40 |
PG29-MA | PG29 | 13~20 | 37 | 9 | 40 |
PG36-MA | PG36 | 22~33 | 47 | 9 | 50 |
PG36-MA | PG36 | 20~26 | 47 | 9 | 50 |
PG42-MA | PG42 | 32~38 | 54 | 10 | 57 |
PG42-MA | PG42 | 25~31 | 54 | 10 | 57 |
PG48-MA | PG48 | 37~44 | 59.3 | 11 | 64 |
PG48-MA | PG48 | 29-35 | 59.3 | 11 | 64 |
M-M Metric type cable glandModel | Thread Size | Applicable to cable Range mm | Thread diameter O.D. L2(mm) | Thread length L1( mm) | Spanner Size |
M12-M | M12*1.5 | 3~6.5 | 12 | 5 | 14 |
M14-M | M14*1.5 | 3~6.5 | 14 | 6 | 17 |
M16-M | M16*1.5 | 5~9 | 16 | 6 | 17 |
M18-M | M18*1.5 | 6.5~11 | 18 | 6 | 20 |
M20-M | M20*1.5 | 7~13 | 20 | 6 | 22 |
M22-M | M22*1.5 | 9~14 | 22 | 6 | 24 |
M24-M | M24*1.5 | 9~14 | 24 | 7 | 30 |
M25-M | M25*1.5 | 9~14 | 25 | 7 | 30 |
M27-M | M27*1.5(2) | 11~18 | 27 | 7 | 30 |
M30-M | M30*1.5(2) | 11~18 | 30 | 7 | 37 |
M32-M | M32*1.5(2) | 15-22 | 32 | 8 | 37 |
M33-M | M33*1.5(2) | 15-22 | 33 | 8 | 37 |
M36-M | M36*1.5(2) | 18-26 | 36 | 8 | 42 |
M40-M | M40*1.5(2) | 18~26 | 40 | 8 | 46 |
M42-M | M42*1.5(2) | 18-26 | 42 | 9 | 52 |
M48-M | M48*1.5(2) | 24~33 | 48 | 9 | 52 |
M50-M | M50*1.5(2) | 30~38 | 50 | 9 | 60 |
M54-M | M60*1.5(2) | 30~38 | 54 | 9 | 60 |
M60-M | M60*1.5(2) | 34-45 | 60 | 9 | 70 |
M63-M | M63*1.5(2) | 34-45 | 63 | 10 | 70 |
M64-M | M64*1.5(2) | 34-45 | 64 | 10 | 70 |
Cable gland M-LM long type threadModel | Thread Size | Applicable to cable Range mm | Thread diameter O.D. L2(mm) | Thread length L1( mm) | Spanner Size |
M12-LM | M12*1.5 | 3~6.5 | 12 | 10 | 14 |
M14-LM | M14*1.5 | 3~6.5 | 14 | 10 | 17 |
M16-LM | M16*1.5 | 5~9 | 16 | 10 | 17 |
M18-LM | M18*1.5 | 6.5~11 | 18 | 10 | 20 |
M20-LM | M20*1.5 | 7~13 | 20 | 10 | 22 |
M22-LM | M22*1.5 | 9~14 | 22 | 10 | 24 |
M24-LM | M24*1.5 | 9~14 | 24 | 11 | 30 |
M25-LM | M25*1.5 | 9~14 | 25 | 12 | 30 |
M27-LM | M27*1.5(2) | 11~18 | 27 | 12 | 30 |
M30-LM | M30*1.5(2) | 11~18 | 30 | 14 | 37 |
M32-LM | M32*1.5(2) | 15-22 | 32 | 14 | 37 |
M33-LM | M33*1.5(2) | 15-22 | 33 | 14 | 37 |
M36-LM | M36*1.5(2) | 15-22 | 36 | 14 | 42 |
M40-LM | M40*1.5(2) | 18~26 | 40 | 15 | 46 |
M42-LM | M42*1.5(2) | 18-26 | 42 | 15 | 46 |
M48-LM | M48*1.5(2) | 24~33 | 48 | 15 | 52 |
M50-LM | M50*1.5(2) | 30~38 | 50 | 15 | 60 |
M54-LM | M60*1.5(2) | 30~38 | 54 | 15 | 60 |
M60-LM | M60*1.5(2) | 34-45 | 60 | 15 | 70 |
M63-LM | M63*1.5(2) | 34-45 | 63 | 15 | 70 |
M64-LM | M64*1.5(2) | 34-45 | 64 | 15 | 70 |
Metallic Cable gland NPT-M typeNPT Type | Thread Size | Applicable to cable Range mm | Thread diameter O.D. L2(mm) | Thread length L1( mm) | Spanner Size |
NPT3/8"-M | NPT3/8" | 4~8 | 17.1 | 13 | 18 |
NPT3/8"-M | NPT3/8" | 2~6 | 17.1 | 5 | 18 |
NPT1/2"-M | NPT1/2" | 6~12 | 21.3 | 13 | 22 |
NPT1/2"-M | NPT1/2" | 5~9 | 21.3 | 13 | 22 |
NPT3/4"-M | NPT3/4" | 13~18 | 26.6 | 15 | 30 |
NPT3/4"-M | NPT3/4" | 9~16 | 26.6 | 15 | 30 |
NPT1"-M | NPT1" | 18~25 | 33.5 | 16 | 40 |
NPT1"-M | NPT1" | 13~20 | 33.5 | 16 | 40 |
NPT1 1/4"-M | NPT1 1/4" | 9~14 | 42 | 18 | 50 |
NPT1 1/4"-M | NPT1 1/4" | 6~12 | 42 | 18 | 50 |
NPT1 1/2"-M | NPT1 1/2" | 32~38 | 48 | 18 | 57 |
NPT1 1/2"-M | NPT1 1/2" | 20~26 | 48 | 18 | 57 |
