220V GFCI Receptacle Electrical Disconnectors (MPD/FRD)

Andeli Group Co., Ltd.
  • Model：Mpd,Frd
  • Type：Terminal Block
  • Material：Copper
  • Transport Package：Carton
  • Specification：ISO9001: 2008; CCC, CE, CB
  • Trademark：ANDELI

Base Info

  • Model NO.：MPD,FRD
  • Origin：China
  • Production Capacity：10000 Pieces,Day

Description

ITEM.NO. Thickness(mm) Dimension(mm) Color
b F D d H L
MPD1.25-156 0.4 4.0 11.0 2.7 1.7 10.0 21.0 Red
Lead section:1.5~2.5mm2(16~14) Max current:=15A
ITEM.NO. Thickness(mm) Dimension(mm) Color
b F D d H L
MPD2-156 0.4 4.0 16.0 2.7 1.7 10.0 21.0 Blue
MPD2-195 0.4 5.0 16.0 2.7 1.7 10.0 21.0
Lead section:4~6mm2(12~10) Max current:=24A
ITEM.NO. Thickness(mm) Dimension(mm) Color
b F D d H L
MPD5.5-195 0.4 4.0 11.0 4.5 3.4 14.0 25.0 Yellow
Lead section:0.5~1.5mm2(22~16) Max current:=10A
ITEM.NO. Thickness(mm) Dimension(mm) Color
b F D d H L
FRD1.25-156 0.4 4.0 16.0 2.7 1.7 13.0 24.5 Red
Lead section:1.5~2.5mm2(16~14) Max current:=15A
ITEM.NO. Thickness (mm) Dimension(mm) Color
b F D d H L
FRD2-156 0.4 4.0 6.3 3.3 2.3 14.0 24.5 Blue
FRD2-195 0.4 5.0 7.0 3.3 2.3 14.0 24.5
Lead section:4~6mm2(12~10) Max current:=24A
ITEM.NO. Thickness(mm) Dimension(mm) Color
b F D d H L
FRD5.5-195 0.4 5.0 7.0 4.5 3.4 14.0 29.5 Yellow
