Waterproof Cable Gland Brass Nickel Plated Pg16
Yueqing Jixiang Connector Co., Ltd.- Certification：RoHS, ISO, CE, Reach
- Surface Treatment：Electroplating
- Color：Metallic Color
- IP Rating：IP68
- Material：Brass
- Type：Straight Head
Base Info
- Model NO.：PG16
- Transport Package：,
- Specification：PG7-PG63
- Trademark：JXLJQ
- Origin：Zhejiang Province, China
- HS Code：33039649
- Production Capacity：5000 PCS,Week
Description
PG thread seriesCode Thread AG Cable range
(mm) Thread O.D
(mm) Mounting Hole
Diamter (mm) Thread Length
GL(mm) Spanner size
(mm) JX-PG7A-NP PG7 6.5-3 12.5 12.5-12.7 7 14 JX-PG7B-NP PG7 2-5 12.5 12.5-12.7 7 14 JX-PG9A-NP PG9 4-8 15.2 15.2-15.4 8 18 JX-PG9B-NP PG9 2-6 15.2 15.2-15.4 8 18 JX-PG11A-NP PG11 5-10 18.6 18.6-18.8 8 20/21 JX-PG11B-NP PG11 3-7 18.6 18.6-18.8 8 20/21 JX-PG13.5A-NP PG13.5 6-12 20.4 20.4-20.6 8 22 JX-PG13.5B-NP PG13.5 5-9 20.4 20.4-20.6 8 22 JX-PG16A-NP PG16 10-14 22.5 22.5-22.7 9 24 JX-PG16B-NP PG16 6-12 22.5 22.5-22.7 9 24 JX-PG19A-NP PG19 10-14 25 25-25.2 9 24/27 JX-PG19B-NP PG19 8-16 25 25-25.2 9 27 JX-PG21A-NP PG21 13-18 28.3 28.3-28.5 9 30/32 JX-PG21B-NP PG21 9-16 28.3 28.3-28.5 9 30/32 JX-PG25A-NP PG25 22-15 32 32-32.2 10 35 JX-PG25B-NP PG25 20-16 32 32-32.2 10 35 JX-PG29A-NP PG29 25-18 37 37-37.2 11 40 JX-PG29B-NP PG29 20-13 37 37-37.2 11 40 JX-PG36A-NP PG36 33-25 47 47-47.2 12 50 JX-PG36B-NP PG36 26-20 47 47-47.2 12 50 JX-PG42A-NP PG42 38-32 54 54-54.2 13 57 JX-PG42B-NP PG42 31-25 54 54-54.2 13 57 JX-PG48A-NP PG48 44-37 59.3 59.3-59.5 14 64 JX-PG48B-NP PG48 35-29 59.3 59.3-59.5 14 64 JX-PG63-NP PG63 52-42 72 72-72.2 15 78
What we do:
Application Scope
Every Small Unit Plays a Great Role
Welcome to send inquiry to us..(We provide customization service)
