• Model NO.：M8-18
• Fuction：Protect Wires Safely
• Benefit：Free Samples
• Temperature：-40 to 100 Degree
• Claw：PA
• Sealing Ring：Silicone
• Sealing Rubber：Silicone
• Transport Package：100,50 PCS Per Bag
• Specification：Metric type
• Trademark：JIXIANG
• Origin：Zhengjiang Province, Cn
• HS Code：33039649
• Production Capacity：30000 PCS , Week

Material: Brass (with nickel plated), stainless steel 304/316Claw: siliconSealing and Sealing Ring: siliconApprovals: ISO9001, CE (TUV)Protection Rate: IP68Temperature Resistance: -40 Degree to 100 degree, short time to 120 degreeFunction: Extremely easy installation, simply insert cable through the assembled gland and tighten gland locknut till cable is secured. These cable glands are designed to withstand water, dust, salt, acid-base, alcohol, oil and common solvent.



      SPECIFICATION


Metal Cable Gland - Silicone Series

Product Code

Thread AG

Applicable cable range(mm)

Thread O.D.(mm)

Mounting Hole Diameter(mm)

Thread length GL(mm)

Joint length H(mm)

Spanner Size (mm)

JX-M8-Sl

M8*1

5.5-2

8

8-8.2

5

16

12

JX-M12A-Sl

M12*1

6.5-3

12

12-12.2

7

19

14

JX-M12B-Sl

M12*1.25

8-3

12

12-12.2

7

16

16

JX-M12C-Sl

M12*1.5

8-3

12

12-12.2

7

16

16

JX-M14-Sl

M14*1.5

8-3

14

14-14.2

7

16

16

JX-M16-Sl

M16*1.5

9-4

16

16-16.2

8

20

20/18

JX-M18-Sl

M18*1.5

9-4

18

18-18.2

8

20

20

NOTE: Customization is availiable for silicone brass cable glands.
More details just contact our sales. The material can be stainless steel,brass with nickel plated. The silicone rubber can be tailored made according to your requests.
