• Model NO.：SLGFY210B
• Specification：3,8′′-4′′
• Origin：Zhejiang, China
• Production Capacity：10000 Pieces Per Month

Inside Diameter

Outside Dia

Over Jacket

Min.Bend

 Radius

Length

of Roll

  Min(mm)Max(mm)Min(mm)Max(mm)(mm)(mm)3/8''-12mmSLGFY210B12.3012.8017.5018.0060301/2''-16mmSLGFY220B15.8016.3020.8021.3080303/4''-20mmSLGFY230B20.7021.2026.2026.70100301''-25mmSLGFY240B26.0026.6032.7033.40150301-1/4''-32mmSLGFY250B34.7035.4041.4042.20180201-1/2''-38mmSLGFY260B40.0040.6047.4048.30200202''-51mmSLGFY270B51.3051.9059.4060.30250152-1/2''-64mmSLGFY280B63.0063.6072.1072.00300103''-75mmSLGFY290B78.0078.7087.9088.90450104''-100mmSLGFY300B101.60102.60113.20114.206005

Competitive Advantage:



+Working Temperature:-10ºC ~ +80ºC

+Excellent waterproof , insulation and tensile strength

+PVC surface thickened layer, smooth appearance ,and with flame retardant
+Square locked structure increase the tensile strength,not easily broken or deformed
+Internal smooth structure is very easy for the entry of wire and cable

+Packing:

(1)  Stretch film packaging

(2)  Stretch film + woven bag packaging

(3)  Stretch film + carton packaging

(4)  Also can add paper disc in the middle of each flexible conduit
