Self-Locking Nylon Cable Ties
Yueqing Aukeman Trading Co., Ltd.- Material：Plastic
- Type：Cable Tie
- Fire Proof Standard：94V-2
- Factory：Professional
- Certificate：CE, TUV, RoHS
- Transport Package：Standard Packing
Base Info
- Trademark：AKMAN
- Origin：China
Description
| ITEM. NO. | Length | W(mm) | Bundle diameter E(mm) | Min. loop tensile strength | ||
| INCH | MM | LBS | KGS | |||
| 3× 60 | 2 3/8" | 60 | 2.5 | 2-12 | 18 | 8 |
| 3× 80 | 3 3/16" | 80 | 2.5 | 2-16 | 18 | 8 |
| 3× 100 | 4" | 100 | 2.5 | 2-22 | 18 | 8 |
| 3× 120 | 4 3/4" | 120 | 2.5 | 2-30 | 18 | 8 |
| 3× 150 | 6" | 150 | 2.5 | 2-35 | 18 | 8 |
| 3× 160 | 6 1/4" | 160 | 2.5 | 2-40 | 18 | 8 |
| 3× 180 | 7" | 160 | 2.5 | 2-42 | 18 | 8 |
| 3× 200 | 8" | 200 | 2.5 | 3-50 | 18 | 8 |
| 4× 100 | 4" | 100 | 3.5 | 3-22 | 40 | 18 |
| 4× 120 | 4 3/4" | 120 | 3.5 | 3-30 | 40 | 18 |
| 4× 150 | 6" | 150 | 3.5 | 3-35 | 40 | 18 |
| 4× 180 | 7" | 180 | 3.5 | 3-42 | 40 | 18 |
| 4× 200 | 8" | 200 | 3.5 | 3-50 | 40 | 18 |
| 4× 250 | 10" | 250 | 3.5 | 3-65 | 40 | 18 |
| 4× 280 | 11" | 280 | 3.5 | 3-75 | 40 | 18 |
| 4× 300 | 11 7/8" | 300 | 3.5 | 3-80 | 40 | 18 |
| 4× 370 | 14 1/2" | 370 | 3.5 | 3-102 | 40 | 18 |
| 5× 120 | 4 3/4" | 120 | 4.8 | 3-24 | 50 | 22 |
| 5× 160 | 7" | 180 | 4.8 | 3-42 | 50 | 22 |
| 5× 180 | 7" | 180 | 4.8 | 3-42 | 50 | 22 |
| 5× 200 | 8" | 200 | 4.8 | 3-50 | 50 | 22 |
| 5× 250 | 10" | 250 | 4.8 | 3-65 | 50 | 22 |
| 5× 280 | 11" | 280 | 4.8 | 3-75 | 50 | 22 |
| 5× 300 | 11 5/8" | 300 | 4.8 | 3-82 | 50 | 22 |
| 5× 350 | 13 3/4" | 350 | 4.8 | 3-90 | 50 | 22 |
| 5× 370 | 14 1/2" | 370 | 4.8 | 3-98 | 50 | 22 |
| 5× 400 | 15 3/4" | 400 | 4.8 | 3-105 | 50 | 22 |
| 5× 430 | 17" | 430 | 4.8 | 3-115 | 50 | 22 |
| 5× 450 | 17 3/4" | 450 | 4.8 | 3-118 | 50 | 22 |
| 5× 500 | 19 11/16" | 500 | 4.8 | 3-150 | 50 | 22 |
| 8× 150 | 6" | 150 | 6 | 3-35 | 85 | 38 |
| 8× 200 | 8" | 200 | 7.1 | 3-50 | 120 | 55 |
| 8× 250 | 10" | 250 | 7.1 | 4-63 | 120 | 55 |
| 8× 300 | 11 5/8" | 300 | 7.1 | 4-82 | 120 | 55 |
| 8× 350 | 13 3/4" | 350 | 7.1 | 4-90 | 120 | 55 |
| 8× 370 | 14 1/4" | 370 | 7.1 | 4-98 | 120 | 55 |
| 8× 400 | 15 3/4" | 400 | 7.1 | 4-105 | 120 | 55 |
| 8× 450 | 17 3/4" | 450 | 7.1 | 4-118 | 120 | 55 |
| 8× 500 | 19 11/16" | 500 | 7.1 | 4-150 | 120 | 55 |
| 8× 550 | 21 11/16" | 500 | 7.1 | 8-165 | 120 | 55 |
| 9× 400 | 15 3/4" | 400 | 9 | 8-105 | 120 | 55 |
| 9× 450 | 17 3/4" | 450 | 9 | 8-118 | 175 | 80 |
| 9× 500 | 19 11/16" | 500 | 9 | 4-150 | 175 | 80 |
| 9× 550 | 21 11/16" | 550 | 9 | 8-165 | 175 | 80 |
| 9× 600 | 23 11/16" | 600 | 9 | 8-175 | 175 | 80 |
| 9× 650 | 25 9/16" | 650 | 9 | 8-190 | 175 | 80 |
| 9× 700 | 27 1/2" | 700 | 9 | 10-210 | 175 | 80 |
| 9× 760 | 30" | 760 | 9 | 10-225 | 175 | 80 |
| 9x800 | 31 1/2" | 800 | 9 | 10-240 | 175 | 80 |
| 9× 900 | 35 7/16" | 900 | 9 | 10-270 | 175 | 80 |
| 9× 1020 | 40 1/8" | 1020 | 9 | 10-295 | 175 | 80 |
| 9× 1200 | 47 1/4" | 1200 | 9 | 10-320 | 175 | 80 |
| 12× 650 | 25 9/16" | 650 | 12 | 14-190 | 240 | 110 |
| 15x200 | 8" | 200 | 15 | 3-50 | 260 | 120 |
| 15x250 | 10" | 250 | 15 | 4-63 | 260 | 120 |
| 15x300 | 11 5/8" | 300 | 15 | 4-82 | 260 | 120 |
