Flexibel Conduit Fittings of Squeeze Connector 90 Degree Angle /Straight Type
TOPELE ENTERPRISE CO., LTD.- Color：Silver
- Surface Treatment：Galvanised
- Application：Bond Flexible Metal Conduit to Box
- Material：Zinc
- Type：90 Degree
- Transport Package：Carton Box + Packing Belt
Base Info
- Model NO.：SCN
- Trademark：TOPELE
- Origin：China
- HS Code：7307990000
- Production Capacity：50000 PCS Per Month
Description
Basic Info.
Model NO. SCN Trademark TOPELE Origin China HS Code 7307990000 Production Capacity 50000 PCS Per MonthProduct Description
Flexibel Conduit Fittings of Squeeze Connector 90 Degree Angle /Straight Type
Basic details:
Material: | Zinc |
Type: | Non-insulated |
Size: | 1/2" to 4" |
Threaed Standard: | NPT |
Usage: | Bonds flexible metal conduit to box or metal enclosure |
Brand Name: | TOPELE |
Standard: | UL |
Specifications:
Size | Width(inch) | Depth(inch) |
3/8" | 1.740 | 0.43-0.69 |
1/2" | 2.110 | 0.64-0.98 |
3/4" | 2.400 | 0.76-1.12 |
1" | 2.870 | 1.08-1.68 |
1-1/4" | 4.000 | 1.35-1.85 |
1-1/2" | 6.000 | 1.56-2.54 |
2" | 6.000 | 1.68-2.56 |
2-1/2" | 7.187 | 2.45-2.95 |
3" | 7.875 | 2.95-3.35 |
| 4'' | 10.200 | 3.75-4.45 |
Size | Dim A(inch) | Dim B(inch) |
3/8" | 1.000 | 0.58-0.62 |
1/2" | 1.468 | 0.74-0.95 |
3/4" | 1.581 | 0.88-1.12 |
1" | 1.750 | 1.14-1.38 |
1-1/4" | 1.912 | 1.42-1.65 |
1-1/2" | 2.090 | 1.68-1.95 |
2" | 2.341 | 2.08-2.56 |
2-1/2" | 2.811 | 2.85-3.25 |
3" | 3.840 | 3.33-3.65 |
| 4'' | 4.562 | 4.18-4.58 |
TOPELE squeeze connector is used to bond cables and conduits to electrical junction boxes and enclosures.It can be bonded using built in set screws, squeeze clamps, screw threads, or saddle mount devices. It suitable for the flexible metal conduits from 1/2" to 4".
