Galvanized Steel/ Aluminum Alloy Cable Tray with Cover
Chongqing Tianbao Conductor Busbar Electrical Co., Ltd.- Certification：CCC, ISO
- Hole：with Hole
- Feature：Antimagnetic, Easy Installation, Light Weight, Dustproof, Corrosion Resistance
- Surface Treatment：Hot Galvanizing
- Material：Stainless Steel
- Type：Trunking
Base Info
- Model NO.：XQJ
- Width：200-800mm
- Side Rail Height：60-200mm
- Max. Working Load：50-150kg
- Standard Length：6m
- Transport Package：Ply Wood Case
- Specification：ISO9001
- Trademark：Tianbao
- Origin：Chongqing, China
- HS Code：76109000
- Production Capacity：10000 Meters Per Month
Description
Modelb(mm) h(mm) Weight(kg) XQJ-P-01 -6-2 200 60 20.39 -10-2 100 28.71 -15-2 150 34.44 -6-3 300 60 30.07 -10-3 100 33.73 -15-3 150 40.59 -6-4 400 60 45.78 -10-4 100 45.78 -15-4 150 51.9 -6-5 500 60 53.54 -10-5 100 59.51 -15-5 150 67.12 -6-6 600 60 65.97 -10-6 100 67.15 -15-6 150 75.29 -6-8 800 60 76.57 -10-8 100 82.37 -15-8 150 94.57 Remark:h=60,100 is single row connect hole, h=150 is double row connect holes.
Main parts of Trunking Cable Tray:
1.Straight segments
2.Horizontal elbows(Various shapes including tees and crosses.)
3.Supporting arm
4.Hanger bracket
5.Connection accessories
Supporting arm typesBolt and pressing board are inlcudedTB-01A-15 190 1.67 TB-01A-20 240 1.83 TB-01A-25 290 1.98 TB-01A-30 340 2.14 TB-01A-40 440 2.48 TB-01A-50 540 2.99 TB-01A-60 640 5.17 TB-01A-80 840 7.03 TB-01A-100 1040 8.95
TB-01A-15 190 1.67 TB-01A-20 240 1.83 TB-01A-25 290 1.98 TB-01A-30 340 2.14 TB-01A-40 440 2.48 TB-01A-50 540 2.99 TB-01A-60 640 5.17 TB-01A-80 840 7.03 TB-01A-100 1040 8.95 TB-03-15 190 1.21 TB-03-20 240 1.29 TB-03-25 290 1.71 TB-03-30 340 1.76 TB-03-40 440 2.34 TB-03-50 540 2.83 TB-03-60 640 3.41 TB-03-80 840 4.29 TB-03-100 1040 5.2 TB-03A-15 190 0.63 TB-03A-20 240 0.78 TB-03A-25 290 1.36 TB-03A-30 340 1.62 TB-03A-40 440 2.15 TB-03A-50 540 2.93 TB-03A-60 640 4.15 TB-03A-80 840 5.83 TB-03A-100 1040 7.85 TB-04-15 190 1.06 TB-04-20 240 1.24 TB-04-25 290 1.28 TB-04-30 340 1.33 TB-04-40 440 1.58 TB-04-50 540 1.78 TB-04-60 640 2.52 TB-04-80 840 2.75 TB-04-100 1040 3.14
We can also supply other types of cable trays
1.Ladder type
material: FRP, steel, aluminum alloy
2.Tough type
material: FRP, steel, aluminum alloy
Main parts of Trunking Cable Tray:
1.Straight segments
2.Horizontal elbows(Various shapes including tees and crosses.)
3.Supporting arm
4.Hanger bracket
5.Connection accessories
Supporting arm typesBolt and pressing board are inlcuded
We can also supply other types of cable trays
1.Ladder type
material: FRP, steel, aluminum alloy
2.Tough type
material: FRP, steel, aluminum alloy
