• Model NO.：Y1
• Operating Temperature：-55~105 ºC
• Raychem/Tyco：302K,402W,502K
• Semi-Rigid Outer Layer：Cross Linked Polyolefin
• Insulation Protection：Spiral Adhesive and Handwork Adhesive
• Voltage Class：600V
• Heat Shrink：Molded Parts
• Two Cores：Three Cores
• Four Cores：Six Cores
• Transport Package：Neutral Packaging
• Trademark：UPM
• Origin：Dalian China
• HS Code：854720

Y1-LVB Low Voltage Black Cable Breakout BootsFeatures      Moulded heat shrinkable cable breakout boots    Operating temperature: -55~105ºC      Insulation, protection and sealing     Shrink temperature: 120~140  ºC      Life expectancy of 20 years at -55ºC to105ºC    Shrink ratio:≥ 2:1     Spiral / hand work adhesive both available    Voltage class: 1 KV      Flame retardant (optional )   Technical DataPropertyTest method          Values          PhysicalTensile strengthASTM D2671   ≥12 MPa Breakdown elongationASTM D2671   ≥400%   Aging                         (136ºC /168hrs)Tensile strengthASTM D2671   ≥10 MPaBreakdown elongationASTM D2671    ≥300% Water absorption ASTM D570    ≤0.5% DensityASTM D26711.1~1.2 Thermal enduranceIEC 216-55~105ºC Low temperature flexibility(-55ºC/4hrs)ASTM D2671No cracking Heat shock (200ºC/4hrs)ASTM D2671No drop, No flowElectricalVolume resistivityASTM D2671 ≥1014 Ω.cm Dielectric strengthASTM D2671≥18 KV/mm Typical application Ideal for energy supply infrastructure, chemical factories, oil refineries, metallurgy, harbor or other locations where safety and reliability of energy supplies are vital for daily operations.Ordering Standard color : BlackStandard packaging by pieces Please specify specification, quantity when orderingCross referenceRaychem/ Tyco : 302K/402W/502K DimensionsReferenceAs supplied (mm)After recovered(mm)Length ±20%(mm)Thickness Nom.(after recovered)Size forUPM Y1-LVBBig endLegBig endLegTotal lengthLeg lengthBig endLegconductor (mm2)Spiral adhesive Y1-2/1s3012144.5 93232.62.24-25Y1-3/1s3816154.5 110352.12.14-35Y1-3/2s5825258.0 165503.02.550-150Y1-3/3s80383511.0 185553.53.5Y1-3/4s95443013.0 205453.52.5185-300Y1-3/5s110504617.5 260654.04.0Y1-3/6s125575520.0 260754.04.0Y1-3/7s170777528.0 280804.04.0Y1-4/1s4015143.5 105252.22.04-35Y1-4/2s5521205.0 150403.12.635-70Y1-4/3s6526267.0 175453.32.970-150Y1-4/4s100473812.0 198584.03.0185-300Y1-4/5s160706419.0 260754.04.0Handwork adhesive Y1-2/0h2111134110402.82.210-16Y1-2/1h3215216110402.82.225-50Y1-2/2h45222610130493.02.770-120Y1-2/3h52304016130493.22.8150-240Y1-3/00h3714226130532.42.24-6Y1-3/0h5023299170663.22.810-16Y1-3/1h75323812190733.22.825-50Y1-3/2h84374315195733.22.870-120Y1-3/3h100475516195753.53.5150-240Y1-3/4h129607528205803.53.5300-400Y1-4/0h3410195150582.82.010-16Y1-4/1h4514268150563.02.525-50Y1-4/2h6424339180663.02.570-120Y1-4/3h78313912195733.02.5150-240Y1-4/4h91304514190743.03.0300-400Y1-5/0h3711245130533.02.210-16Y1-5/1h5114288150603.02.225-50Y1-5/2h7623369170763.02.270-120Y1-5/3h91304613180703.22.5150-240
Frequently Asked Q & A

Q1. You are a manufacturer or trading company?

A: We are a leading manufacturer of shrinkable materials,with best price,high quality and short lead time.
Q2. Can you accept sample orders?

A:Yes, we can accept sample orders and we can also provide free samples for your test if necessary.

Q3. What is your MOQ?

A:Normally, for standard thin wall heat shrink, MOQ is 300m. For standard medium/heavy wall tube MOQ is 500m per size.

Q4. What are your payment terms?

A: As usual, the trade term is FOB Dalian. For order amount less than 10,000 USD, it should be 100% T/T in advance. For order amount over 10,000 USD, 30% deposit and 70% balance against copy of BL is acceptable.

Q5. How can I get my order?

A: Per your requirements, we will arrange the cargo delivered by express (e.g. TNT, DHL, FedEx ) ,by land,by air or by sea. After that, we will give you the tracking number or other relative files for your reference.

Q6. How about your quality?

A: We are a trust worthy supplier for GE,Siemens for more than 10 years. Most of the products got the CE,UL,DNV,CCS and Rohs approval. Let's start with a small trial order or free samples before the formal order, then you will get a clear image about the product quality and the relevant cost for transportation.

Q7. How is the delivery time?
A: Usually within 3 weeks.

Q8. Could you offer certificate of origin (e.g. Form-A,Form-E,Form-F,Form-R)?
A: It is totally not a problem. To help you enjoy the tariff concession,we can prepare the relevant certificate of origin.
