M12*1.5 Pg Stainless Steel Cable Glands Strain Relief IP68 Waterproof Cord Grips
Yueqing Jixiang Connector Co., Ltd.- Certification：CCC, RoHS, ISO, CE
- Surface Treatment：Electroplating
- Color：Metallic Color
- IP Rating：IP68
- Material：Nickel Plated Brass
- Type：Straight Head
Base Info
- Model NO.：M8-M100, PG7-PG63
- Factory Report：ISO90001
- Thread Type：Metric
- Claw：PA
- Seal Material：NBR
- Working Temperature：-40~10, Short Time to 120
- Transport Package：Standard Export Carton
- Specification：Customization
- Trademark：JXLJQ
- Origin：China Mainland
- HS Code：8547901000
- Production Capacity：3000000PCS,Month
Description
These cable glands are designed to withstand water,dust,salt,acid-base,alcohol,oil and common solvent.
Product Details Images
Metric Thread Type Size Chart
| Product Code | Thread AG | cable range (mm) | Thread O.D.(mm) | Mounting Hole Diameter (mm) | Thread length GL(mm) | Spanner Size (mm) |
| JX-M8-NP | M8*1 | 5.5-2 | 8 | 8-8.2 | 5 | 12 |
| JX-M10-NP | M10*1 | 6.5-3 | 10 | 10-10.2 | 7 | 14 |
| JX-M12-NP | M12*1.5 | 6.5-3 | 12 | 12-12.2 | 7 | 14 |
| JX-M14-NP | M14*1.5 | 4-8 | 14 | 14-14.2 | 7 | 17 |
| JX-M16-NP | M16*1.5 | 4-8 | 16 | 16-16.2 | 8 | 18 |
| JX-M18-NP | M18*1.5 | 5-10 | 18 | 18-18.2 | 8 | 20 |
| JX-M20-NP | M20*1.5 | 6-12 | 20 | 20-20.2 | 8 | 22 |
| JX-M22-NP | M22*1.5 | 10-14 | 22 | 22-22.2 | 8 | 24 |
| JX-M24-NP | M24*1.5 | 10-14 | 24 | 24-24.2 | 9 | 24/27 |
| JX-M25A-NP | M25*1.5 | 10-14 | 25 | 25-25.2 | 9 | 24/27 |
| JX-M25B-NP | M25*1.5 | 8-16 | 25 | 25-25.2 | 9 | 27 |
| JX-M25C-NP | M25*1.5 | 18-13 | 25 | 25-25.2 | 9 | 30/27 |
| JX-M27A-NP | M27*1.5 | 18-13 | 27 | 27-27.2 | 9 | 30 |
| JX-M27B-NP | M27*2 | 18-13 | 27 | 27-27.2 | 9 | 30 |
| JX-M28A-NP | M28*1.5 | 18-13 | 28 | 28-28.2 | 9 | 30 |
Product Packaging & Shipping
Cable gland packing Details: Poly bag with label + Standard export carton with label.Delivery Details: Normally 7 working days after received the payment.
Certifications
