Good Quality CE RoHS Reach Multiple Entry Metal Waterproof Pg7 Brass Cable Gland Silicon Rubber Insert Type Cable Connector

Yueqing Jixiang Connector Co., Ltd.
  • Certification：CCC, RoHS, ISO, CE, IP68
  • Surface Treatment：Electroplating
  • Color：Metalic
  • IP Rating：IP68
  • Material：Brass
  • Type：Straight Head

Base Info

  • Model NO.：M8-M100, PG7-PG63
  • Transport Package：Polybag+Label Export Carton Box
  • Specification：Metric
  • Trademark：Jixiang
  • Origin：Zhejiang; China
  • HS Code：8547909000
  • Production Capacity：50000PCS,Week

Description

Product Name:Silicon Rubber cable glandMain material:Nickel-plated brassStandard size:M8-M20; PG7-PG13.5Certification:RoHS, CE, TUV, IP68, ISO9001Notes:Customization service is available

Good Quality CE RoHS Reach Multiple Entry Metal Waterproof Pg7 Brass Cable Gland Silicon Rubber Insert Type Cable Connector

AG itemCable Range(mm)Thread O.D.(mm)Thread Length(mm)Spanner Size(mm)cable gland M8x12-48512M10x1.252-410514M12x1.52-412714M12x1.54-612714M14x1.54-614716M14x1.52-414716M16x1.56-816820M18x1.56-818820M18x1.58-1018820M20x1.58-1020822M20x1.510-1220822cable gland PG72-412.5714PG74-612.5714PG94-615.2818PG96-815.2818PG116-818.6820/21PG118-1018.6820/21PG13.58-1020.4822PG13.510-1220.4822

More size information, kindly contact us directly.. We provide customization service !
