EMC Brass Cable Gland with TPV Sealing Ring - Metric Type

Yueqing Jixiang Connector Co., Ltd.
  • Certification：CCC, ISO, CE
  • Surface Treatment：Electroplating
  • Color：Metalic Color
  • IP Rating：IP68
  • Material：Brass
  • Type：Straight Head

Base Info

  • Model NO.：M12-63
  • Fuction：Protect Wires Safely
  • Benefit：Free Samples
  • Temperature：-40 to 100 Degree
  • Claw：PA
  • Sealing Ring：NBR
  • Sealing Rubber：PA
  • Bottom Part：Copper
  • Transport Package：100,50 PCS Per Bag
  • Specification：Metric type
  • Trademark：JIXIANG
  • Origin：Zhengjiang Province, Cn
  • HS Code：33039649
  • Production Capacity：10000 PCS , Week

Description

Material: Brass (with nickel plated)Claw: PA6 V2Sealing and Sealing Ring: TPV,NBRInsert :Polyamide, halogen-free acc. toEMC Brush:brass wireApprovals: ISO9001, CE (TUV)Protection Rate: IP68Temperature Resistance: -25 Degree to 100 degree, fixed: -40 to +100 degreeFunction: EMC Cable gland is designed for use with armoured,elastometric and plastic cable  or braided cables were EMC is required. Suitable for both indoor and outdoor applications, seals on cable outer sheath to IP68 and it fitted with patented EMC membrance, suitable to carry on cable shield.


      SPECIFICATION

EMC Brass Cable Gland--G thread type,NPT thread type

CODE

Thread AG

Cable range(mm)

Thread O.D.(mm)

Thread no. per inch

Thread length GL(mm)

Joint length H(mm)

Spanner size (mm)

JX-D.G1/4-EMC

G1/4

6.5-3

13.1

19

7

19

14

JX-D.G3/8-EMC

G3/8

8-4

16.6

19

8

19

18

JX-D.G1/2-EMC

G1/2

12-6

20.9

14

8

22

22

JX-D.G3/4-EMC

G3/4

18-13

26.4

14

9

25

30

JX-D.G1- EMC

G1

25-18

33.2

11

11

29

40

JX-D.G1- 1/4-EMC

G1-1/4

33-25

41.9

11

13

35

50

JX-D.G1-1/2-EMC

G1-1/2

38-32

47.8

11

14

37

57

JX-D.G2-EMC

G2

44-37

59.6

11

14

38

64

JX-D.G2- 1/2-EMC

G2-1/2

52-42

75.1

11

15

38

77

JX-D.G3-EMC

G3

70-65

87.8

11

15

48

94

JX-D.NPT 1/4- EMC

NPT1/4

6.5-3

13.6

18

7

19

14

JX-D.NPT 3/8- EMC

NPT3/8

8-4

17

18

8

19

18

JX-D.NPT 1/2- EMC

NPT1/2

12-6

21.2

14

8

22

22

JX-D.NPT 3/4- EMC

NPT3/4

18-13

26.5

14

9

25

30

JX-D.NPT 1- EMC

NPT1

25-18

33.2

11.5

11

29

40

JX-D.NPT 1-1/4- EMC

NPT1-1/4

33-25

41.9

11.5

13

35

50

JX-D.NPT 1-1/2- EMC

NPT1-1/2

38-32

48

11.5

14

37

57

JX-D.NPT 2- EMC

NPT2

44-37

60

11.5

14

38

64

JX-D.NPT 2-1/2- EMC

NPT2-1/2

52-42

72.6

8

15

38

78

JX-D.NPT 3- EMC

NPT3

70-65

88.6

8

15

45

98



EMC Brass Cable Gland with TPV Sealing Ring - Metric TypeEMC Brass Cable Gland with TPV Sealing Ring - Metric TypeEMC Brass Cable Gland with TPV Sealing Ring - Metric TypeEMC Brass Cable Gland with TPV Sealing Ring - Metric TypeEMC Brass Cable Gland with TPV Sealing Ring - Metric Type










NOTE: Customization is availiable!!!!
