Conduit Fitting 90 Degree Flexible Right Angle Cable Gland M16
Yueqing Jixiang Connector Co., Ltd.- Certification：CCC, RoHS, ISO, CE
- Surface Treatment：Electroplating
- Color：Metallic Color
- IP Rating：IP67
- Material：Nickel Plated Brass ,SS304,SS316L
- Type：Torsion Resistance
Base Info
- Model NO.：M12~M64,PG,G Type
- Factory Report：ISO90001
- Thread Type：Metric,Pg,G
- Transport Package：Standard Export Carton
- Specification：Customization
- Trademark：JXLJQ
- Origin：China Mainland
- HS Code：8547901000
- Production Capacity：3000000PCS,Month
Description
1. It can be used in flexible metallic conduit or liquid tight conduit in power plant, power transmission system, building factory etc. And it protects the electrical wire or cable outside the construction and plant.
2.Use to positively bone the conduit to a box or enclosure.
90 Degree Elbow Metal Conduit Fittings - Metric ThreadProduct Code Thread O.D Cable range (mm) Length (mm) Thread length GL(mm) Spanner Size (mm) JX-M12-9D 12 3-6.5 45 9 20/21 JX-M16-6.5-9D 16 3-6.5 45 9 20/21 JX-M16-8-9D 16 4-8 45 9 20/21 JX-M16-10-9D 16 5-10 57 10 20/25 JX-M18-9D 18 5-10 57 10 20/25 JX-M20-10-9D 20 5-10 57 10 24/25 JX-M20-12-9D 20 6-12 57 10 24/30 JX-M20-14-9D 20 8-14 58 15 24/30 JX-M22-9D 22 8-14 58 15 24/30 JX-M24-12-9D 24 6-12 58 15 24/30 JX-M24-14-9D 24 10-14 58 15 24/30 JX-M25-14-9D 25 10-14 58 15 28/34 JX-M25-16-9D 25 10-16 75 15 30/34 JX-M25-18-9D 25 13-18 75 15 28/34 JX-M27-16-9D 27 10-16 75 15 30/34 JX-M27-18-9D 27 13-18 75 15 28/34 JX-M30-16-9D 30 10-16 75 15 30/34 JX-M30-18-9D 30 13-18 75 15 30/34 JX-M32-18-9D 32 13-18 75 15 30/34 JX-M32-22-9D 32 15-22 75 15 30/43 JX-M32-25-9D 32 18-25 90 15 40/43 JX-M33-9D 33 18-25 90 15 40/43 JX-M36-22-9D 36 15-22 90 15 36/43 JX-M36-25-9D 36 18-25 90 15 40/43 JX-M40-25-9D 40 18-25 90 15 40/43 JX-M40-30-9D 40 22-30 105 15 50/55 JX-M40-32-9D 40 22-32 115 15 50/55 JX-M42-9D 42 22-32 115 15 50/55 JX-M48-9D 48 22-32 115 15 50/55 JX-M50-9D 50 30-38 115 15 55/60 JX-M56-9D 56 30-38 115 15 55/60 JX-M60-9D 60 37-44 125 18 65/70 JX-M63-9D 63 37-44 125 18 75/75 JX-M64-9D 64 37-44 125 18 65/70
2.Use to positively bone the conduit to a box or enclosure.
90 Degree Elbow Metal Conduit Fittings - Metric Thread
Q: Are you trading company or manufacture?
A: We are manufacturer and have focus on cable glands for over 10 years.Our advantage are lower prices and the ability to provide customized services compared to trading companies.Q: What about the lead time for mass production?
A: Your goods can be delivered in 3-7 days if it is the standard models and in stock.For special model or large order, you can negotiate the delivery date with us.Q: Can you provide the free samples?
A: Yes, we can offer the samples for free charge, meanwhile, the cost of freight is on your account.Q: Can I have a visit to your factory before the order?
A: Yes, welcome to our factory! You also can visit our factory by video for inconvenient time.
