• Model NO.：HS-SW
• Thermal Rating：125t
• Maximum Voltage：600V
• Transport Package：100m,Roll or Customized
• Specification：UL
• Trademark：ES
• Origin：China
• HS Code：39173200
• Production Capacity：5000000, 000 M,Month

SPECIFICATIONS
MATERIAL:
POLYOLEFIN (CROSSLINKED)FEATURE:FLAME RETARDANTVOLTAGE:600 V
STANDARD:
UL 224 125°C & RoHSWALL TYPE:SINGLESHRINK TEMP:90°CWORK TEMP:-55°C~125°CRATIO:2:1
UL FILE:
E197895
EASE CODE
AS SUPPLIED (mm)
AFTER RECOVERY (mm)Inside
Diameter (D)Wall
Thickness (T)Inside
Diameter (D)Wall
Thickness (T)(D)(T)(d)(t)mminchmmmminchmmHS-SW-1.2/0.6-LT
≥1.2
3/64
0.20 ± 0.08
≤0.6
3/128
0.40 ± 0.08
HS-SW-1.6/0.8-LT
≥1.6
1/16
0.20 ± 0.08
≤0.8
1/32
0.40 ± 0.08
HS-SW-2.4/1.2
≥2.4
3/32
0.20 ± 0.09
≤1.0
3/64
0.42 ± 0.08
HS-SW-3.2/1.6
≥3.2
1/8
0.25 ± 0.09
≤1.5
1/16
0.48 ± 0.10
HS-SW-4.8/2.4
≥4.8
3/16
0.25 ± 0.09
≤2.0
3/32
0.54 ± 0.10
HS-SW-6.4/3.2
≥6.4
1/4
0.28 ± 0.10
≤3.0
1/8
0.50 ± 0.10
HS-SW-9.5/4.7
≥9.5
3/8
0.30 ± 0.12
≤4.5
3/16
0.72 ± 0.12
HS-SW-12.7/6.3
≥12.7
1/2
0.30 ± 0.12
≤6.0
1/4
0.72 ± 0.12
HS-SW-16/8
≥16.0
5/8
0.36 ± 0.12
≤8.0
5/16
0.70 ± 0.12
HS-SW-19.1/9.5
≥19.1
3/4
0.38 ± 0.15
≤10.0
3/8
0.80 ± 0.15
HS-SW-25.4/12.7
≥25.4
1
0.42 ± 0.15
≤12.5
1/2
0.90 ± 0.15
HS-SW-32/16
≥32.0
1-1/4
0.45 ± 0.15
≤15.0
5/8
0.97 ± 0.15
HS-SW-38.1/19
≥38.1
1- 1/2
0.50 ± 0.15
≤21.0
3/4
1.10 ± 0.15
HS-SW-50.8/25.4
≥50.8
2
0.50 ± 0.15
≤27.0
1
1.10 ± 0.15
HS-SW-76.2/38.1≥76.230.70 ± 0.30≤38.11-1/21.25 ± 0.20HS-SW-101.6/50.8≥101.640.70 ± 0.30≤50.821.25 ± 0.20HS-SW-127/63.5≥127.050.70 ± 0.30≤63.52-1/21.40HS-SW-152.4/76.2≥152.460.70 ± 0.30≤76.231.40HS-SW-177.8/88.9≥177.870.70 ± 0.30≤88.93-1/21.40HS-SW-203.2/101.6≥203.280.70 ± 0.30≤101.641.40HS-SW-228.6/114.3≥228.690.70 ± 0.30≤114.34-1/21.40TECHNICAL DATA
PROPERTY
DATACONDITIONTensile Strength≥10.4MPa
 Tensile Strength After Aging≥7.3MPa158°C ± 1.0°C, 168 hrsElongation≥200%
 Elongation After Aging≥100%134°C 60 daysLongitudinal Change<±5%
 Radial Shrinking Ratio≥50%
 FlammabilityVW-1
 Dielectric StrengthNo BreakdownAt 1 Min, AC2500VVolume Resistivity≥10 * 1012 Ω.cm
 CorrosionNo Corrosion
 Copper Stability≥100%
 Concentricity70%
