Stainless Steel Cable Gland Metric Thread
Yueqing Jixiang Connector Co., Ltd.- Certification：CCC, RoHS, ISO, CE
- Surface Treatment：Electroplating
- Color：Metallic
- IP Rating：IP68
- Material：Stainless Steel
- Type：Straight Head
Base Info
- Model NO.：Metric series
- Transport Package：100 PCS Per Bag
- Specification：pg type
- Trademark：JIXIANG
- Origin：Zhengjiang Province
- HS Code：33039649
- Production Capacity：30000 PCS , Week
Description
Metric threadProduct Code Thread AG Cable range
(mm) Thread O.D.
(mm) Thread length
GL(mm) Spanner Size
(mm) JX-M8-SS M8*1.0 2-5.5 8 5 12 JX-M10-SS M10*1.0 3-6.5 10 7 14 JX-M12-SS M12*1.5 3-6.5 12 7 14 JX-M14-SS M14*1.5 4-8 14 7 17 JX-M16-SS M16*1.5 4-8 16 8 18 JX-M18-SS M18*1.5 5-10 18 8 20 JX-M20-SS M20*1.5 6-12 20 8 22 JX-M22-SS M22*1.5 10-14 22 8 24 JX-M24-SS M24*1.5 10-14 24 9 24/27 JX-M25A-SS M25*1.5 10-14 25 9 24/27 JX-M25B-SS M25*1.5 8-16 25 9 27 JX-M25C-SS M25*1.5 13-18 25 9 30/27 JX-M27A-SS M27*1.5 13-18 27 9 30 JX-M27B-SS M27*2.0 13-18 27 9 30 JX-M28A-SS M28*1.5 13-18 28 9 30 JX-M28B-SS M28*2.0 13-18 28 9 30 JX-M30A-SS M30*1.5 13-18 30 9 30/32 JX-M30B-SS M30*2.0 13-18 30 9 30/32 JX-M32A-SS M32*1.5 15-22 32 10 35 JX-M32B-SS M32*1.5 16-20 32 10 35 JX-M32C-SS M32*2.0 15-22 32 10 35 JX-M33A-SS M33*1.5 15-22 33 10 35 JX-M33B-SS M33*2.0 15-22 33 10 35 JX-M36A-SS M36*1.5 18-25 36 10 40 JX-M36B-SS M36*2.0 18-25 36 10 40 JX-M37A-SS M37*1.5 18-25 37 10 40 JX-M37B-SS M37*2.0 18-25 37 10 40 JX-M40A-SS M40*1.5 18-25 40 11 40/45 JX-M40B-SS M40*2.0 18-25 40 11 40/45 JX-M40C-SS M40*1.5 22-30 40 11 45 JX-M40D-SS M40*2.0 22-30 40 11 45 JX-M42A-SS M42*1.5 22-30 42 11 45 JX-M42B-SS M42*2.0 22-30 42 11 45 JX-M47A-SS M47*1.5 25-33 47 11 50 JX-M47B-SS M47*2.0 25-33 47 11 50 JX-M48A-SS M48*1.5 25-33 48 11 50/52 JX-M48B-SS M48*2.0 25-33 48 11 50/52 JX-M50A-SS M50*1.5 32-38 50 12 50/55 JX-M50B-SS M50*2.0 32-38 50 12 50/55 JX-M54A-SS M54*1.5 32-38 54 12 57 JX-M54B-SS M54*2.0 32-38 54 12 57 JX-M56A-SS M56*1.5 32-38 56 12 57/59 JX-M56B-SS M56*2.0 32-38 56 12 57/59 JX-M60A-SS M60*1.5 37-44 60 13 64 JX-M60B-SS M60*2.0 37-44 60 13 64 JX-M63A-SS M63*1.5 37-44 63 13 64/68 JX-M63B-SS M63*2.0 37-44 63 13 64/68 JX-M64A-SS M64*1.5 37-44 64 13 64/68 JX-M64B-SS M64*2.0 37-44 64 13 64/68 JX-M72-SS M72*2.0 42-52 72 15 78 JX-M75-SS M75*2.0 42-52 75 15 78 JX-M80-SS M80*2.0 50-62 80 15 86/88 JX-M88-SS M88*2.0 60-70 88 15 98 JX-M100-SS M100*2.0 70-80 100 15 110
Product Images:
What we do:
Application Scope
Every Small Unit Plays a Great Role
Welcome to send inquiry to us..(We provide customization service)
