• Model NO.：Y1-MVR
• Operating Temperature：-55~105 ºC
• Raychem/Tyco：Ccba
• Semi-Rigid Outer Layer：Cross Linked Polyolefin
• Insulation Protection：Handwork Adhesive
• Voltage Class：24-36 Kv
• Heat Shrink：Molded Parts
• Red Sealant Liner：Insulation Protection
• Transport Package：Neutral Packaging
• Trademark：UPM
• Origin：Dalian China
• HS Code：854720

Y1-MVR Medium Voltage Red Cable Breakout BootsFeatures  Moulded anti-tracking cable breakout boots  Operating temperature: -55~105ºC  Insulation, protection,shield   Shrink temperature: 120~140  ºC  Life expectancy of 20 years at -55ºC to105ºC  Shrink ratio:≥ 2:1  Red sealant liner   Voltage class: 24~36 KV  Flame retardant (optional ) Technical DataPropertyTest method          Values          PhysicalTensile strengthASTM D2671   ≥10 MPa Breakdown elongationASTM D2671   ≥350%   Aging                                                    (136ºC /168hrs)Tensile strengthASTM D2671   ≥8 MPaBreakdown elongationASTM D2671    ≥250% Water absorption ASTM D570    ≤0.5% DensityASTM D26711.1~1.2 Thermal enduranceIEC 216-55~105ºC Low temperature flexibility(-55ºC/4hrs)ASTM D2671No cracking Heat shock (200ºC/4hrs)ASTM D2671No drop, No flowElectricalVolume resistivityASTM D2671 ≥1014 Ω.cm Dielectric strengthASTM D2671≥20 KV/mm Anti-tracking ASTM 2303  No tracking DimensionsReferenceAs supplied (mm)After recovered(mm)Length ±20%(mm)Thickness ± 10%(mm)Size forUPM Y1-MVRBig endLegBig endLegTotal lengthLeg lengthBig endLegconductor (mm2)Y1-3/0r5825268 165503.02.510-16Y1-3/1r75323812 210703.52.525-50Y1-3/2r100475516 235854.03.070-120Y1-3/3r129607528 220804.03.0150-240  Typical application      Ideal for energy supply infrastructure, chemical factories, oil refineries, metallurgy, harbor or other       locations where safety and reliability of energy supplies are vital for daily operations.Ordering      Standard color : Red     Standard packaging by pieces     Please specify specification, quantity when orderingCross referenceDSG Canusa: CCBAFrequently Asked Q & A

Q1. You are a manufacturer or trading company?

A: We are a leading manufacturer of shrinkable materials,with best price,high quality and short lead time.
Q2. Can you accept sample orders?

A:Yes, we can accept sample orders and we can also provide free samples for your test if necessary.

Q3. What is your MOQ?

A:Normally, for standard thin wall heat shrink, MOQ is 300m. For standard medium/heavy wall tube MOQ is 500m per size.

Q4. What are your payment terms?

A: As usual, the trade term is FOB Dalian. For order amount less than 10,000 USD, it should be 100% T/T in advance. For order amount over 10,000 USD, 30% deposit and 70% balance against copy of BL is acceptable.

Q5. How can I get my order?

A: Per your requirements, we will arrange the cargo delivered by express (e.g. TNT, DHL, FedEx ) ,by land,by air or by sea. After that, we will give you the tracking number or other relative files for your reference.

Q6. How about your quality?

A: We are a trust worthy supplier for GE,Siemens for more than 10 years. Most of the products got the CE,UL,DNV,CCS and Rohs approval. Let's start with a small trial order or free samples before the formal order, then you will get a clear image about the product quality and the relevant cost for transportation.

Q7. How is the delivery time?
A: Usually within 3 weeks.

Q8. Could you offer certificate of origin (e.g. Form-A,Form-E,Form-F,Form-R)?
A: It is totally not a problem. To help you enjoy the tariff concession,we can prepare the relevant certificate of origin.
