High Quanlity Fire Resistance Heat Shrinking Tube
ZHEJIANG MAXWEL INSULATION TECHNOLOGY CO., LTD.- Certification：UL, RoHS, ISO, CE
- Color：Red, Blue, Yellow, Green, etc
- IP Rating：IP50
- Usage：Electric Wire
- Material：Polyolefin
- Type：Heat Shrinkable
Base Info
- Model NO.：PHST
- Application：Electrical Winding Insulation
- Chemistry：Hybrid Insulation
- Thermal Rating：Y 90
- Maximum Voltage：<10kv
- Classification：Hybrid Insulation Materials
- Brand：Maxwel
- Voltage：600V
- Initial Shrinking Temperature：70c
- Temperature：-50-125c
- Shrinking Ratio：2:1
- Fully Shrinking Temperature：125c
- Transport Package：Exporting Carton
- Specification：UL, ROHS
- Trademark：Maxwel
- Origin：Wenzhou
- HS Code：39173100
- Production Capacity：10, 000 Meters,Day
Description
SizeDimensio nbefore shrinking (mm)Dimensio nafter shrinking (mm)Standard packaging (m/disc)Application
(mm)Internal diameterWall thicknessMaxinternal diameterWall thickness2.02.4 ± 0.30.25 ± 0.050.9 ± 0.10.35 ± 0.052001.1~1.83.03.4 ± 0.40.25 ± 0.051.4 ± 0.10.40 ± 0.052001.6~2.74.04.5 ± 0.40.25 ± 0.051.8 ± 0.10.45 ± 0.052002.1~3.65.05.4 ± 0.40.25 ± 0.0523 ± 0.10.55 ± 0.151002.6~4.56.06.4 ± 0.40.28 ± 0.152.8 ± 0.20.55 ± 0.151003.1~5.47.07.4 ± 0.40.28 ± 0.153.3 ± 0.20.55 ± 0.151003.7~6.38.08.4 ± 0.50.28 ± 0.153.8 ± 0.20.55 ± 0.151004.2~7.21010.5 ± 0.50.30 ± 0.154.8 ± 0.20.55 ± 0.151005.2~9.01212.5 ± 0.50.30 ± 0.155.7 ± 0.30.60 ± 0.151006.2~111414.5 ± 0.50.35 ± 0.156.7 ± 0.30.60 ± 0.151007.3~131616.5 ± 0.60.38 ± 0.157.7 ± 0.30.65 ± 0.151008.3~152021.0 ± 0.80.40 ± 0.159.7 ± 0.30.75 ± 0.1510010.4~192525.8 ± 0.80.45 ± 0.1511.0 ± 1.00.75 ± 0.15012.8~243030.8 ± 0.80.45 ± 0.1514.0 ± 1.00.75 ± 0.155016~293535.8 ± 0.80.50 ± 0.2016.0 ± 1.00.85 ± 0.205018~344042.0 ± 1.00.50 ± 0.2019.0 ± 1.00.85 ± 0.205021~395051.0 ± 1.00.50 ± 0.2024.0 ± 1.00.85 ± 0.205026~496061.0 ± 1.00.65 ± 0.2029.0 ± 1.00.85 ± 0.202535~557071.0 ± 1.00.65 ± 0.2033.0 ± 2.01.00 ± 0.202540~658081.0 ± 1.00.65 ± 0.2037.0 ± 2.01.00 ± 0.202545~759091.0 ± 1.00.65 ± 0.2043.0 ± 2.01.00 ± 0.202550~88100102.0 ± 2.00.65 ± 0.2048.0 ± 2.01.00 ± 0.202555~95120122.0 ± 2.00.80 ± 0.2058.0 ± 2.01.50 ± 0.201565~115150152.0 ± 2.00.80 ± 0.2073.0 ± 2.01.50 ± 0.201580~145180182.0 ± 2.00.80 ± 0.2088.0 ± 2.01.50 ± 0.201595~175wire coat and insulationmake the joint of terminal block and wire insulateddevide the colorswater-proofprotection and insualtion of insistors and electrical capacitors
Features:
Shrink ratio: 2: 1
Operating temperature: -55 to 125 degree
Minimum fully recovery temperature: 110degree
Longitudinal shrinkage≤ 5%
Soft, Flammability, Environmental protection
The specification range from 1.0mm to 180mm, special specification is accepted.
Easy to operate, shrinking with the drying oven and the hot air gun
Standard color: Yellow and green Interaction
