• Model NO.：JBC-2
• HS Code：850000
• Production Capacity：500000

Basic Info.

Model NO. JBC-2 HS Code 850000 Production Capacity 500000

Product Description

Application

Abroad usage in the low voltage insulation lines, leading the branch connection from the

main conductor, T-connection of low voltage insulation wire service and cable branch

connection for building distribution system.





Details
1). Simple installation. Need not strip the cable coat.
2). Moment nut, piercing pressure is constant, keep good electric connection and make no damage to lead.
3). Self-seam frame, wetproof, and anti-corrosion, extend the using life of insulated lead and connector
4). A dopted special connecting tablet, apply to joint of Cu(AL)and Cu(AL)or Cu and Al
5). Small electric connecting resistance, connecting resistance less than 1.1 times of the resistance of branch conductor with teh same length.
6). Special insulated case body, resistandce to illumination and environmental aging. The insulation strength can up to 12kV
7). Arc surface design, apply to connectrion with the same(different)diameter, wide connectrion scope(0.75mm2-400mm2)

Item No.	Main wire section	Branch wire section	Bolt
JBC-0	25-70	6-35	1
JBC-1	35-70	6-35	1
JBC-2	35-150	35-150	1
JBC-3	50-240	50-150	2
