• Model NO.：S3(n)
• Semi-Rigid Outer Layer：Cross Linked Polyolefin
• RoHS Compliant：EVA Adhesive
• Thermal Melt Adhesive：Electrical Wiring
• Raychem：Mwtm,Bsts,Sst-M
• Sealing Protection：Cable Joint
• Gas Pipeline Protection：Direct Buried
• Transport Package：Neutral Packaging
• Trademark：UPM
• Origin：Dalian China
• HS Code：39173900

S3(n) Medium Wall Halogen Free Heat Shrink Tube Features       Medium wall cross-linked polyolefin     Operating temperature: -55~105ºC       Thermal melt adhesive liner     Shrink temperature: 125 ºC       High resistance to abrasion and impact      Shrink ratio: 3:1       Halogen free   Dimensions3:1ReferenceAs supplied(mm)After recovered(mm)Standard lengthUPM S3(n)ID min.ID max.WT nom.m8/2822.01.22 9/3932.01.22 12/41242.01.22 16/51652.21.22 19/61962.51.22 22/62262.51.22 25/82582.51.22 28/62862.51.22 33/83382.51.22 35/1235122.51.22 40/1240122.51.22 45/1345132.51.22 55/1655162.71.22 65/1965192.81.22 75/2275223.01.22 85/2585253.01.22 95/2595253.01.22 115/34115343.01.22 130/36130363.01.22 140/42140423.01.22 160/50160503.01.22 175/58175583.01.22 200/65200653.01.22 230/75230753.01.22 260/85260853.01.22 350/1103501103.61.22      Technical DataPropertyTest method          Values          PhysicalTensile strengthASTM D2671   ≥12 MPa Breakdown elongationASTM D2671   ≥400%   Aging                            (158ºC /168hrs)Tensile strengthASTM D2671   ≥12 MPaBreakdown elongationASTM D2671   ≥350% Water absorption ASTM D570    ≤0.5% DensityASTM D26711.05~1.10 Low temperature flexibility(-55ºC/4hrs)ASTM D2671No cracking Heat shock (200ºC/4hrs)ASTM D2671No drop, No flow(outer layer only) Hardness(Shore D)ASTM D267148HD Adhesive softening point ASTM E28≥85ºC Adhesive peel strength to XLPEASTM D2671110 N/25cm Adhesive peel strength to steelASTM D267180 N/25cmElectricalVolume resistivityASTM D2671≥1014 Ω.cm Dielectric strengthASTM D267115 KV/mmChemical Fungus resistanceASTM G21No growth Copper corrosionASTM D2671No corrosion ID=Internal DiameterWT=wall thicknessTypical application      Ideal for insulation,sealing, protection of cable joints,gas pipeline and low voltage electrical wiring      Designed to withstand severe mechanical, direct buried installation requirementsOrdering      Standard color : Black     Special colors (e.g. Red, Clear) are available on request      Standard product is adhesive lined, tubes witout adhesive are available on request.     Standard packaging is 1.22m/pc     Please specify specification, color, quantity when orderingCross referenceRaychem/ Tyco :MWTM /BSTS/ SST-M Frequently Asked Q & A

Q1. You are a manufacturer or trading company?

A: We are a leading manufacturer of shrinkable materials,with best price,high quality and short lead time.
Q2. Can you accept sample orders?

A:Yes, we can accept sample orders and we can also provide free samples for your test if necessary.

Q3. What is your MOQ?

A:Normally, for standard thin wall heat shrink, MOQ is 300m. For standard medium/heavy wall tube MOQ is 500m per size.

Q4. What are your payment terms?

A: As usual, the trade term is FOB Dalian. For order amount less than 10,000 USD, it should be 100% T/T in advance. For order amount over 10,000 USD, 30% deposit and 70% balance against copy of BL is acceptable.

Q5. How can I get my order?

A: Per your requirements, we will arrange the cargo delivered by express (e.g. TNT, DHL, FedEx ) ,by land,by air or by sea. After that, we will give you the tracking number or other relative files for your reference.

Q6. How about your quality?

A: We are a trust worthy supplier for GE,Siemens for more than 10 years. Most of the products got the CE,UL,DNV,CCS and Rohs approval. Let's start with a small trial order or free samples before the formal order, then you will get a clear image about the product quality and the relevant cost for transportation.

Q7. How is the delivery time?
A: Usually within 3 weeks.

Q8. Could you offer certificate of origin (e.g. Form-A,Form-E,Form-F,Form-R)?
A: It is totally not a problem. To help you enjoy the tariff concession,we can prepare the relevant certificate of origin.
