Heat Shrinkable Sleeve RoHS Heat Shrink Tube PE Plastic Material

Wenzhou Zhechi Electric Co., Ltd.
  • Certification：CE
  • Color：5 Colors
  • IP Rating：IP68
  • Usage：Optical Cable, Electric Wire
  • Material：PE
  • Type：Heat Shrinkable

Base Info

  • Rated Voltage：10kv
  • Tensile Strength：2:1
  • Temperature Range：E: -55ºC to +125ºC
  • Size：Diameter 1~180
  • End Shrink Temperature：≥120ºC
  • Wall Thickness：0.4-1.4mm
  • Transport Package：100m,Roll
  • Trademark：ZC
  • Origin：China
  • Production Capacity：50000 Rolls, Month

Description

Product name:XLPE Heat Shrinkable tubeReference standard:UL224&CSA22.2Operating temperature:-55ºC-125ºCShrink Temperature:121ºCFull-recovery temperature:90ºCRated voltage:600V,300VFlame-resistant class:VW-1Tensile Strength:10.4MpaElongation:>200%Radial shrinking ratio: 2:1Longitudinal shrinking ratio: <±5%Oil resistance:Good to Excellent Copper corrosion: no corrosion
