Plastic Watertight Corrugated Tubing Fitting Gland -Metric Type
Yueqing Jixiang Connector Co., Ltd.- Certification：RoHS, ISO, CE
- Surface Treatment：Other
- Color：Black
- IP Rating：IP68
- Material：Nylon
- Type：Straight Head
Base Info
- Model NO.：AD10-AD18.5
- Claw：PA
- Transport Package：Standard Export Package
- Specification：36*26*19
- Trademark：Jixiang
- Origin：Zhejiang
- HS Code：8547901000
- Production Capacity：1000000piece,Year
Description
Nylon Conduit Fitting - Metric, PG, G(PF) Thread
Item No.
Accommodated Pipes
Thread
Thread O.D. C1 (mm)
Thread Length C2 (mm)
JX-M12-NC10
AD 10
M12*1.5
12
9
JX-M16-NC13
AD 13
M16*1.5
16
10
JX-M16-NC13L
M16*1.5
16
15
JX-M16-NC15.8
AD 15.8
M16*1.5
16
15
JX-M20-NC15.8
M20*1.5
20
10
JX-M20-NC15.8L
M20*1.5
20
15
JX-M22-NC15.8
M22*1.5
22
15
JX-M25-NC15.8
M25*1.5
25
15
JX-M16-NC18.5
AD 18.5
M16*1.5
16
15
JX-M20-NC18.5
M20*1.5
20
10
JX-M20-NC18.5L
M20*1.5
20
15
JX-M22-NC18.5
M22*1.5
22
15
JX-M16-NC21.2
AD 21.2
M16*1.5
16
15
JX-M20-NC21.2
M20*1.5
20
15
JX-M25-NC21.2
M25*1.5
25
10
JX-M25-NC21.2L
M25*1.5
25
15
JX-M25-NC25
AD 25
M25*1.5
25
15
JX-M25-NC28.5
AD 28.5
M25*1.5
25
15
JX-M32-NC34.5
AD 34.5
M32*1.5
32
15
JX-M40-NC42.5
AD 42.5
M40*1.5
40
15
JX-M50-NC42.5
M50*1.5
50
15
JX-M50-NC48.5
AD 48.5
M50*1.5
50
15
JX-M50-NC54.5
AD 54.5
M50*1.5
50
25
JX-M63-NC54.5
M63*1.5
63
25
JX-PG7-NC10
AD 10
PG7
12.5
9
JX-PG9-NC10
PG9
15.2
10
JX-PG9-NC13
AD 13
PG9
15.2
10
JX-PG11-NC13
PG11
18.6
10
JX-PG11-NC15.8
AD 15.8
PG11
18.6
10
JX-PG13.5-NC15.8
PG13.5
20.4
10
JX-PG16-NC15.8
PG16
22.5
10.8
JX-PG13.5-NC18.5
AD 18.5
PG13.5
20.4
10
JX-PG16-NC18.5
PG16
22.5
10.8
JX-PG16-NC21.2
AD 21.2
PG16
22.5
10.8
JX-PG21-NC21.2
PG21.2
28.3
13
JX-PG21-NC25
AD 25.0
PG21
28.3
13
JX-PG21-NC28.5
AD 28.5
PG21
28.3
13
JX-PG29-NC34.5
AD 34.5
PG29
37
13
JX-PG36-NC42.5
AD 42.5
PG36
47
15
JX-PG42-NC42.5
PG42
54
16
JX-PG42-NC48.0
AD 48.0
PG42
54
16
JX-PG48-NC54.5
AD 54.5
PG48
59.3
26
JX-PF1/4-NC10
AD 10
G(PF)1/4''
13.1
9
JX-PF3/8-NC13
AD 13
G(PF)3/8''
16.6
15
JX-PF1/2-NC15.8
AD 15.8
G(PF)1/2''
20.9
15
JX-PF1/2-NC18.5
AD 18.5
G(PF)1/2''
20.9
15
JX-PF1/2-NC21.2
AD 21.2
G(PF)1/2''
20.9
15
JX-PF3/4-NC21.2
G(PF)3/4''
26.4
15
JX-PF3/4-NC28.5
AD 28.5
G(PF)3/4''
26.4
15
JX-PF1-NC34.5
AD 34.5
G(PF)1''
33.2
15
JX-PF1 1/4-NC42.5
AD 42.5
G(PF)1 1/4''
41.9
15
JX-PF1 1/2-NC54.5
AD 54.5
G(PF)1 1/2''
48
15
JX-PF2-NC54.5
G(PF)2''
60
26
More size information, kindly contact us directly.. We provide customization service !
