• Model NO.：FTTX-PT-J16
• Warranty：1 Year
• Fiber Capacity：16
• Single Weight(Kg)：1kg
• MOQ：10
• Color：OEM
• Delivery Time：15 Days
• Transport Package：Paper Box
• Specification：16C
• Trademark：Softel
• Origin：China
• HS Code：85176229
• Production Capacity：1000 Set Per Week

Basic Info.

Model NO. FTTX-PT-J16 Warranty 1 Year Fiber Capacity 16 Single Weight(Kg) 1kg MOQ 10 Color OEM Delivery Time 15 Days Transport Package Paper Box Specification 16C Trademark Softel Origin China HS Code 85176229 Production Capacity 1000 Set Per Week

Product Description

Description:

The material is engineering plastic of high quality and it can be used for indoor, outdoor.; It is applicable for wall-mounted and pole-mounted.;

Features:
 1.Water-proof design with IP-65 Protection level.2.Integrated with splice cassette and cable management rods.3.Manage fibers in a reasonable fiber radius condition.4.Easy to maintain and extend the capacity.5.Fiber bend radius control more than 40mm.6.Suitable for the fusion splice or mechanical splice.7.2pcs of 1*8 PLC Splitter can be installed as an option.8.Efficient cable management.9.1 mid-span cable entrance for feeder cable(2 ports), 16 ports
10. for 4-7mm drop cable.



Configuration

Model		FTTX-PT-J16
Box material		PC+ABS
Fiber capacity		16 cores
Size(mm)		292x 218 x 83
Single Weight(kg)		1.4kg
Installtion size  D*E(mm)		154*82
