Nylon Cable Glands (Metric)
Changhong Plastics Group Imperial Plastics Co., Ltd.- Certification：CCC, RoHS, ISO, CE
- Surface Treatment：Injection
- Color：White
- IP Rating：IP68
- Material：Nylon PA66
- Type：Cable Gland
Base Info
- Model NO.：M12*1.5
- Type of Gland：Pg
- Size：Pg7-Pg42
- Transport Package：Plastic Bags, Headcards
- Specification：M
- Trademark：CHS changhong
- Origin：China
- HS Code：3926909090
Description
Basic Info.
Model NO. M12*1.5 Type of Gland Pg Size Pg7-Pg42 Transport Package Plastic Bags, Headcards Specification M Trademark CHS changhong Origin China HS Code 3926909090Product Description
· Material: Made from UL Nylon 66, 94V-2 and tight ring from rubber.· Feature:
1. Special designation, good strengthsile and none damage to electrical machine.
2. Not need to dismetgrate the fix terminal, cable can be inserted throug directly then tighten easy and save time.
· Application: Used for machinery control box, distribution plate, machine and electrical, etc.
| ITEM.NO. | D1 | D2 | B1 | L1 | L4 | Cable range |
| M12*1.5 | 12 | 8.3 | 6 | 7.9 | 13.3 | 3-6.5 |
| M16*1.5 | 16 | 10.9 | 9.6 | 15 | 15.8 | 5-10 |
| M20S*1.5 | 20 | 14.8 | 12.5 | 15 | 18.4 | 3-7 |
| M20M*1.5 | 20 | 14.8 | 12.5 | 15 | 18.4 | 6-12 |
| M20L*1.5 | 20 | 15.5 | 14.5 | 15 | 19.5 | 10-14 |
| M25*1.5 | 25 | 21 | 18.4 | 15 | 22.3 | 13-18 |
| M32*1.5 | 32 | 26 | 26.2 | 15 | 24.8 | 18-25 |
| M40*1.5 | 40 | 33 | 33.4 | 18 | 31.6 | 25-32 |
| M50*1.5 | 50 | 42.5 | 36.5 | 18 | 31.6 | 30-38 |
| M63*1.5 | 63 | 54.1 | 44 | 18.5 | 32.6 | 34-44 |
