• Model NO.：Metric series
• Samples：All Available
• Transport Package：Standard Export Carton
• Specification：M, PG, NPT, G thread
• Trademark：JXLJQ
• Origin：China Mainland
• HS Code：8547901000
• Production Capacity：50000PCS,Month

EMC Cable Gland ---D series, Metric thread

Product Code

Thread  AG

Cable range(mm)

Thread diameter(mm)

Board caliber(mm)

Thread length GL(mm)

Joint length(mm)

Wrench diameter (mm)

JX-D.M12-EMC

M12*1.5

6.5-3

12

12-12.2

7

19

14

JX-D.M14-EMC

M14*1.5

8-4

14

14-14.2

7

19

17

JX-D.M16-EMC

M16*1.5

8-4

16

16-16.2

8

20

18

JX-D.M18-EMC

M18*1.5

10-5

18

18-18.2

8

21

20

JX-D.M20-EMC

M20*1.5

12-6

20

20-20.2

8

22

22

JX-D.M22-EMC

M22*1.5

14-10

22

22-22.2

8

23

24

JX-D.M24-EMC

M24*1.5

14-10

24

24-24.2

9

25

24/27

JX-D.M25A-EMC

M25*1.5

14-10

25

25-25.2

9

25

24/27

JX-D.M25B-EMC

M25*1.5

18-13

25

25-25.2

9

27

30/27

JX-D.M27A-EMC

M27*1.5

18-13

27

27-27.2

9

27

30

JX-D.M27B-EMC

M27*2

18-13

27

27-27.2

9

27

30

JX-D.M28A-EMC

M28*1.5

18-13

28

28-28.2

9

27

30

JX-D.M28B-EMC

M28*2

18-13

28

28-28.2

9

27

30

JX-D.M30A-EMC

M30*1.5

18-13

30

30-30.2

9

29

30/32

JX-D.M30B-EMC

M30*2

18-13

30

30-30.2

9

29

30/32

JX-D.M32A-EMC

M32*1.5

22-15

32

32-32.2

10

29

35

JX-D.M32B-EMC

M32*2

22-15

32

32-32.2

10

29

35

JX-D.M33A-EMC

M33*1.5

22-15

33

33-33.2

10

29

35

JX-D.M33B-EMC

M33*2

22-15

33

33-33.2

10

29

35

JX-D.M36A-EMC

M36*1.5

25-18

36

36-36.2

10

31

40

JX-D.M36B-EMC

M36*2

25-18

36

36-36.2

10

31

40

JX-D.M37A-EMC

M37*1.5

25-18

37

37-37.2

10

31

40

JX-D.M37B-EMC

M37*2

25-18

37

37-37.2

10

31

40

JX-D.M40A-EMC

M40*1.5

25-18

40

40-40.2

11

31

40/45

JX-D.M40B-EMC

M40*2

25-18

40

40-40.2

11

31

40/45

JX-D.M40C-EMC

M40*1.5

30-22

40

40-40.2

11

35

45

JX-D.M40D-EMC

M40*2

30-22

40

40-40.2

11

35

45

JX-D.M42A-EMC

M42*1.5

30-22

42

42-42.2

11

35

45

JX-D.M42B-EMC

M42*2

30-22

42

42-42.2

11

35

45

JX-D.M47A-EMC

M47*1.5

33-25

47

47-47.2

11

37

50

JX-D.M47B-EMC

M47*2

33-25

47

47-47.2

11

37

50

JX-D.M48A-EMC

M48*1.5

33-25

48

48-48.2

11

37

50/52

JX-D.M48B-EMC

M48*2

33-25

48

48-48.2

11

37

50/52

JX-D.M50A-EMC

M50*1.5

38-32

50

50-50.2

12

37

50/55

JX-D.M50B-EMC

M50*2

38-32

50

50-50.2

12

37

50/55

JX-D.M54A-EMC

M54*1.5

38-32

54

54-54.2

12

38

57

JX-D.M54B-EMC

M54*2

38-32

54

54-54.2

12

38

57

JX-D.M56A-EMC

M56*1.5

38-32

56

56-56.2

12

38

57/59

JX-D.M56B-EMC

M56*2

38-32

56

56-56.2

12

38

57/59

JX-D.M60A-EMC

M60*1.5

44-37

60

60-60.2

13

38

64

JX-D.M60B-EMC

M60*2

44-37

60

60-60.2

13

38

64

JX-D.M63A-EMC

M63*1.5

44-37

63

63-63.2

13

38

64/68

JX-D.M63B-EMC

M63*2

44-37

63

63-63.2

13

38

64/68

JX-D.M64A-EMC

M64*1.5

44-37

64

64-64.2

13

38

64/68

JX-D.M64B-EMC

M64*2

44-37

64

64-64.2

13

38

64/68

JX-D.M72-EMC

M72*2

52-42

72

72-72.2

15

42

65/68

JX-D.M75-EMC

M75*2

52-42

75

75-75.2

15

42

78

JX-D.M80-EMC

M80*2

62-50

80

80-80.2

15

45

86/88

JX-D.M88-EMC

M88*2

70-60

88

88-88.2

15

45

98

JX-D.M100-EMC

M100*2

80-70

100

100-100.2

15

45

110



 Welcome to send inquiry to us..(We provide customization service)
