Htat Soft Polyolefin Double Wall Heat Shrinkable Tube

Union Polymer Material Co., Ltd.
  • Certification：RoHS, ISO
  • Color：Black
  • Usage：Electric Wire
  • Material：PE
  • Type：Heat Shrinkable
  • Transport Package：Carton

Base Info

  • Model NO.：S3T-AF
  • Specification：4mm-18.3mm
  • Trademark：UPM
  • Origin：China
  • HS Code：3917390000
  • Production Capacity：2000tons

Description


After shrink (mm)S3T-AFDiameter(Min.)Diameter(Max.)WT(reference)Adhesive WT(reference)Shrink ratio 4:1     4/14.0 1.0 1.0 0.5  8/2 8.0 2.0 1.2 0.5  12/312.0 3.0 1.4 0.6  16/416.0 4.0 1.7 0.7  24/624.0 6.0 2.2 0.8  32/832.0 8.0 2.4 1.0 52/1352.0 13.0 2.5 1.0 Shrink ratio 3:1    3.2/1.03.2 1.0 1.0 0.5 4.8/1.64.8 1.6 1.0 0.5 6.4/2.16.4 2.1 1.2 0.5 7.9/2.67.9 2.6 1.3 0.6 9.5/3.29.5 3.2 1.4 0.6 12.7/4.212.7 4.2 1.7 0.7 15.0/515.0 5.0 1.8 0.7 19.1/619.1 6.0 2.2 0.8 25.4/825.4 8.0 2.4 1.0  30/1030.0 10.0 2.5 1.0 39/1339.0 13.0 2.5 1.0           Cross Reference    Tyco-Raychem: HTAT    Htat Soft Polyolefin Double Wall Heat Shrinkable TubeHtat Soft Polyolefin Double Wall Heat Shrinkable TubeHtat Soft Polyolefin Double Wall Heat Shrinkable TubeHtat Soft Polyolefin Double Wall Heat Shrinkable TubeHtat Soft Polyolefin Double Wall Heat Shrinkable Tube
