Factory Directly Provide High Quality All Type Brass Cable Gland Size
Wenzhou Zhechi Electric Co., Ltd.- Certification：CCC, RoHS, ISO, CE
- Surface Treatment：Galvanised
- Color：White
- IP Rating：IP68
- Material：Brass
- Type：Straight Head
Base Info
- Thread Type：M,Pg,NPT,G
- Usage：Lock Cable Tight
- Function：Resistant to The Water ,Dust,Oil
- Fire Proof Level：UL94V-2
- Feature：Seal Part Hold Cable Firmly
- Transport Package：Common Packing: Inner Plastic Bag + Export Carto
- Specification：M8-M120 PG7-PG63 G NPT
- Trademark：ZC
- Origin：China
- HS Code：39174000
- Production Capacity：500000PCS,Year
Description
Product Model
Applicable to cable
Thread diameter
Thread length
Wrench diameter
M12x1.5
3~6.5
12
6
14
M16x1.5
4~8
16
7
17
M18x1.5
5~10
18
7
20
M20x1.5
6~12
20
7.5
22
M22x1.5
10~14
22
7.5
24
M25x1.5
13~18
25
8
30
M32x1.5
16~21
32
9
40
M40x1.5
22~32
40
9
50
M50x1.5
32~38
50
10
57
M63x1.5
37~44
63
11
64
