• Model NO.：MPRS
• Voltage Ratings：35kv
• Shrink Ratio：2:1
• Min. Shrink Temperature：84degree
• Min. Full Recovery Temperature：120degree
• Continuous Operating Temperature：-55degree-125degree
• Tensile Strength：8MPa
• Elongation at Break：300%
• Transport Package：Cartons
• Specification：CE, RoHS
• Trademark：VOLSUN
• Origin：China
• HS Code：39269090
• Production Capacity：1000, 000meter,Year

PropertyTypical dataTest MethodTensile strength≥8.0MPaASTM D 2671Elongation at break≥300%ASTM D 2671Tensile strength after heat aging≥6.9MPa130ºC×168hElongation after heat ageing≥100%130ºC×168hLongitudinal change-8%~+8%ASTM D 2671Flammability(Oxygen index)≥27GB/T 2406Heat ShockNo tracksJB 7829Dielectric Strength≥20kv/mmASTM D 149Shore A Hardness≤90GB2411Volume resistivity≥1014Ω.cmIEC 60093



DimensionsStandard package
(M/Roll)Inner diameter dWall thickness wΦ16/8≥16≤81.5±0.125Φ20/10≥20≤101.5±0.1 25Φ25/13≥25≤131.7±0.125Φ30/15≥30≤151.75±0.1 25Φ40/20≥40≤201.75±0.1 25Φ50/25≥50≤251.8±0.1 25Φ60/30≥60≤302.0±0.1 25Φ65/33≥65≤332.0±0.1 25Φ70/35≥70≤352.0±0.1 25Φ80/40≥80≤402.0±0.1 25Φ90/45≥90≤452.0±0.1 25Φ100/50≥100≤502.1±0.15 25Φ120/60≥120≤602.2±0.15 25Φ150/75≥150≤752.3±0.15 25Company profile
