Wire Mesh Cable Tray with Accessories Galvanised Ventilated Carbon Steel T Welding Flat Wire Mesh
HEBEI INNOVAT BUILDING MATERIALS GROUP CO., LTD- Certification：SGS
- Hole：with Hole
- Feature：Easy Installation, Light Weight, Dustproof, Corrosion Resistance
- Surface Treatment：Hot Galvanizing
- Material：Carbon Steel
- Type：Channel
Base Info
- Model NO.：cable tray
- Length：2-6m
- Transport Package：Pallet,Wooden
- Specification：width 50 mm - 1200 mm
- Origin：China
- HS Code：730120
Description
Main Parameter of Hot Dipped Galvanized Wire Mesh Cable Tray:MaterialSurface FinishingThicknss of coatingApplication of environmentQ235 steelElectro Zinc Plating≥12µmIndoorQ235 steelHot dip Galvanized>60µmIndoor,OutdoorQ235 steelPowder Coating>60µmIndoorSS304Acid washingN/AIndoor,OutdoorSS316Acid washingN/AIndoor,Outdoor,High Corrosion occasionsSS316LAcid washingN/AIndoor,Outdoor,High Corrosion occasions Dimension Range of Hot Dipped Galvanized Wire Mesh Cable Tray:DimensionRangeWidth50-1000mmHeight25-200mmLength300-6000mmDiameter of steel wire4mm,5mm,6mm Accessories1.Wire mesh cable tray straight2. Connector assembly 3.Faster Connector4. Straight bracket5. L Bracket6.Splice(Long)7.Tee splice bar8. Hold down plate9. Wall bracket10.Drop-out11.Under floor stand12.bracket arm13.suspension rod14.suspension rod-2
Increased safety-Unique construction ensures the tops of trays are rounded and smooth to protect installers and cables from cuts.
Flexible pathway-Tray can be cut and formed into turns and transitions using standard splices, simplifying design and components selection.
Fast installation-A range of fast-connecting splices and supports speedy assembly and installation.
Electrical continuity-Zinc plating allows bonding through splice connections for electrical continuity.
High corrosion resistance-Electro/Hot galvanised finish is also available
Wide range of accessories-Allows quick interface with electrical fittings and superior support when transitioning network cables.
Increased safety-Unique construction ensures the tops of trays are rounded and smooth to protect installers and cables from cuts.Flexible pathway-Tray can be cut and formed into turns and transitions using standard splices, simplifying design and components selection.
Fast installation-A range of fast-connecting splices and supports speedy assembly and installation.
Electrical continuity-Zinc plating allows bonding through splice connections for electrical continuity.
High corrosion resistance-Electro/Hot galvanised finish is also available
Wide range of accessories-Allows quick interface with electrical fittings and superior support when transitioning network cables.
