- Model NO.：BS-PA-MU-NE
- Colour：Black
- Flame Resistance：V0
- Working Temperature：-60~160t
- Transport Package：Customized
- Specification：UL, RoHS
- Trademark：ES
- Origin：China
- HS Code：39269090
- Production Capacity：50000, 000 Meter,Month
| SPECIFICATIONS |
| MATERIAL: | POLYAMIDE PA66 MULTIFILAMENT |
| COLOUR: | BLACK |
| FLAMMABILITY: | SELF-EXTINGUISHING TO UL94-V0 |
| WORK TEMP: | -60ºC-160ºC |
| MELTING POINT: | 256ºC |
| STANDARD: | UL (File No. E317364) & RoHS & HALOGEN FREE |
| FEATURE: | THE MATERIAL HAS EXCELLENT FLEXIBILITY, HIGH ABRASION AND FLAME RESISTANCE PROPERTY, THE TIGHT WOVEN CONSTRUCTION PROVIDES CHEMICAL FLUID RESISTANCE AND NOISE REDUCTION. |
| APPLICATION: | IDEAL FOR PROTECTING HYDRAULIC PIPES, PLASTIC PIPES, RUBBER HOSE, WIRE HARNESSES AWAY FROM DAMAGE AND ABRASION. |
EASE CODE |
FLAT WIDTH | ROUND I.D. | WALL THICKNESS | PACKING |
| (W) |
|
| m/roll |
| BS-PA-MU-20NE | 20 | 12 | 1.1 | 100 |
| BS-PA-MU-25NE | 25 | 15 | 1.1 | 100 |
| BS-PA-MU-30NE | 30 | 19 | 1.1 | 100 |
| BS-PA-MU-35NE | 35 | 22 | 1.1 | 50 |
| BS-PA-MU-40NE | 40 | 25 | 1.1 | 50 |
| BS-PA-MU-45NE | 45 | 28 | 1.1 | 50 |
| BS-PA-MU-50NE | 50 | 31 | 1.1 | 50 |
| BS-PA-MU-60NE | 60 | 38 | 1.1 | 50 |
| BS-PA-MU-70NE | 70 | 44 | 1.1 | 50 |
| BS-PA-MU-80NE | 80 | 50 | 1.1 | 50 |
| BS-PA-MU-90NE | 90 | 57 | 1.1 | 50 |
| BS-PA-MU-100NE | 100 | 60 | 1.1 | 50 |
| BS-PA-MU-115NE | 115 | 70 | 1.1 | 50 |
| BS-PA-MU-145NE | 145 | 90 | 1.1 | 50 |
| BS-PA-MU-176NE | 176 | 110 | 1.1 | 50 |
| BS-PA-MU-200NE | 200 | 125 | 1.1 | 50 |
