Aerial Suspension ABC Cable Tension Clamp Factory
Qingdao Powtech Electronics Co., Ltd.- Certification：RoHS, ISO, CE
- Color：Black
- Surface Treatment：Oxygenation
- Usage：Electrical Appliance
- Material：Plastic
- Type：Tension Clamp
Base Info
- Model NO.：LA
- Name：Aerial Suspension ABC Cable Tension Clamp
- Transport Package：Wooden Case
- Specification：CE, RoHS, SGS, ISO
- Trademark：OPTELEC
- Origin：China
- HS Code：76169990
- Production Capacity：10000PCS,Month
Description
Model
Conductor(mm2)
Breaking load(kn)
LA1
4x16 / 4x25
2.5
LA1-2x25
2x16 / 2x25
2
LA2
2x6 / 2x16
2.5
Description:
The anchoring clamp is designed to anchor LV ABC lines with insulated neutral messenger.
The galvanized steel /stainless steel flexible bail is equipped with an movable insulating saddle and the two sleeves are compressed on the ends and locked on the clamp body.
Automatic conical tightening. Opening bail easy to be installed.
All the parts secured together.
Standard: NFC33-042.
Material:
Clamp body and wedge made of weather and UV resistance thermoplastic
Adjustable link made of electric galvanized steel or stainless steel(SS).
Features:
A pair of wedges grips the cable automatically within the conical body.
The installation does not require any specific tools and the operating time is drastically reduced.
