Dead End Sets for Opgw Cable Medium / Long Span

Qingdao Powtech Electronics Co., Ltd.
  • Name：Dead End Sets
  • Transport Package：Wooden Case
  • Specification：CE, RoHS, SGS, ISO
  • Trademark：OPTELEC
  • Origin：China

Base Info

  • Model NO.：ONZ
  • HS Code：76169990
  • Production Capacity：10000PCS,Month

Description


S.No
Description
Qty
Material
1
U-bolt
1
Galvanized forge steel
2
U shackle with bolt
2
Galvanized forge steel
3
Extension link PD-7
1
Galvanized forge steel
4
Clevis thimble
1
Galvanized steel
5
Inner armor rods
1
Aluminum clad steel
6
Outer armor rods
1
Aluminum clad steel
7
Parallel groove clamp
1
Aluminum alloy
8
Ground wire 1.5m
1
Aluminum alloy

OPGW tension clamp

Technical data sheet:
Product Model
Cable diameter
Inner Armor Rod
(mm)
Outer Armor Rod
(mm)
Clevis Thimble
Extension link
Anchor Shackle
ONZ-80-11.5
11.0-11.8
1800
1300
LH-1000
PD-7
U-7Installation Guide:
