2 Bolt Insulation Piercing Clamp Jjc-240/240

L&R ELECTRIC GROUP CO., LTD.
  • Certification：ISO, CE
  • Color：Black
  • Surface Treatment：Polishing
  • Usage：Electrical Appliance
  • Material：Copper
  • Type：O Type

Base Info

  • Model NO.：JJC-240,240
  • Nos of Bolt：2
  • OEM ODM：Agree
  • Head Type：Hexagon
  • Transport Package：Carton or as Requirment
  • Specification：compact
  • Trademark：L&R or as requirment
  • Origin：Wenzhou, Zhejiang
  • HS Code：85389000

Description


Type
Suitable wire(mm²)
Main Line(mm²)
Branch line
(mm²)
JJC-300/300
240~300
240~300
JJC-240/240
150~240
150~240
JJC-240/120
150~240
70~120
JJC-240/50
150~240
16~50
JJC-150/150
95~150
95~150
JJC-150/70
95~150
35~70
JJC-95/95
50~95
50~95
JJC-95/50
50~95
10~50
JJC-70/35
16~70
10~35
JJC-95/10
16~95
1.5~10(Street Lamp Branch Line)
JJC-50/10
10~50
1.5~10
JJCD-240~300
240~300
Grounding Connector
JJCD-95~240
95~240
Grounding Connector
JJCD-35~120
35~120
Grounding Connector
JJCD-16~95
16~95
