Stainless Steel Cable Gland Pg11 5-10mm 304/316L
Yueqing Jixiang Connector Co., Ltd.- Certification：CCC, RoHS, ISO, CE
- Surface Treatment：Electroplating
- Color：Metallic
- IP Rating：IP68
- Material：Stainless Steel
- Type：Straight Head
Base Info
- Model NO.：PG series
- Samples：Available
- Transport Package：100 PCS Per Bag
- Specification：pg type
- Trademark：JIXIANG
- Origin：Zhengjiang Province
- HS Code：33039649
- Production Capacity：30000 PCS , Week
Description
PG ThreadProduct Code Thread AG Cable range
(mm) Thread O.D.
(mm) Mounting Hole
Dia (mm) Thread length
GL(mm) Joint Length
(mm) Spanner Size
(mm) JX-PG7A-SS PG7 3-6.5 12.5 12.5-12.7 7 19 14 JX-PG7B-SS 2-5 12.5 12.5-12.7 7 19 14 JX-PG9A-SS PG9 4-8 15.2 15.2-15.4 8 20 17 JX-PG9B-SS 2-6 15.2 15.2-15.4 8 20 17 JX-PG11A-SS PG11 5-10 18.6 18.6-18.8 8 21 20/21 JX-PG11B-SS 3-7 18.6 18.6-18.8 8 21 20/21 JX-PG13.5A-SS PG13.5 6-12 20.4 20.4-20.6 8 22 22 JX-PG13.5B-SS 5-9 20.4 20.4-20.6 8 22 22 JX-PG16A-SS PG16 10-14 22.5 22.5-22.7 9 23 24 JX-PG16B-SS 6-12 22.5 22.5-22.7 9 23 24 JX-PG19A-SS PG19 10-14 25 25-25.2 9 25 24/27 JX-PG19B-SS 8-16 25 25-25.2 9 25 27 JX-PG21A-SS PG21 13-18 28.3 28.3-28.5 9 27 30 JX-PG21B-SS 9-16 28.3 28.3-28.5 9 27 30 JX-PG25A-SS PG25 15-22 32 32-32.2 10 29 35 JX-PG25B-SS 16-20 32 32-32.2 10 29 35 JX-PG29A-SS PG29 18-25 37 37-37.2 11 31 40 JX-PG29B-SS 13-20 37 37-37.2 11 31 40 JX-PG36A-SS PG36 25-33 47 47-47.2 12 37 50 JX-PG36B-SS 20-26 47 47-47.2 12 37 50 JX-PG42A-SS PG42 32-38 54 54-54.2 13 38 57 JX-PG42B-SS 25-31 54 54-54.2 13 38 57 JX-PG48A-SS PG48 37-44 59.3 59.3-59.5 14 38 64 JX-PG48B-SS 29-35 59.3 59.3-59.5 14 38 64 JX-PG63-SS PG63 42-52 72 72-72.2 15 42 77
Welcome to send inquiry to us..(We provide customization service)
(mm)
(mm)
Dia (mm)
GL(mm)
(mm)
(mm)
Welcome to send inquiry to us..(We provide customization service)
