Self-Winding Tube
Union Polymer Material Co., Ltd.- Color：Black
- IP Rating：IP67
- Usage：Electric Wire
- Material：PE
- Type：Braided Tube
- Transport Package：Carton
Base Info
- Model NO.：TT26
- Trademark：upm brand
- Origin：Dalian China
- HS Code：8547200000
- Production Capacity：5000000m
Description
Technical Parameters
Material
PET
Operating temperature
-50ºC-150ºC
Melting point
250ºC±10ºC
Flame retardant
BS6853,UL94 V0,DIN5510
color
black orange yellow
Certification
RoHS
Cutting tool
Laser cutting
Hot cut
| Product number | ID(D) | Max. wire harness diameter | standard packaging |
| TT26- | mm | mm | m/roll |
| 003 | 3 | 4 | 100 |
| 005 | 5 | 6 | 100 |
| 008 | 8 | 9 | 100 |
| 010 | 10 | 11 | 100 |
| 013 | 13 | 14 | 50 |
| 016 | 16 | 17 | 50 |
| 019 | 19 | 20 | 25 |
| 025 | 25 | 27 | 25 |
| 029 | 29 | 31 | 25 |
| 032 | 32 | 34 | 25 |
| 038 | 37 | 40 | 25 |
| 050 | 50 | 52 | 25 |
1,The inner diameter refers to the round diameter of the casing, not the folded diameter.
2,Special packaging, length, special color, etc., can be customized.
3,Please refer to the product specification acknowledgement for detailed product parameters.
