• Model NO.：SBRS-125H (3X)
• Application：Insulators
• Maximum Voltage：<10kv
• Thermal Rating：125degree
• Product：High Insulation Heat Shrink Protective Tube
• Sample：Free for Existing Sample
• Transport Package：Export Standard Cartons
• Specification：CE, RoHS
• Trademark：Volsun
• Origin：Jiangsu
• HS Code：85479090
• Production Capacity：1000000meters,Week

PropertyTypical dataTest method/conditionTensile strength≥10.4MPaASTM D 2671Elongation at break≥300%ASTM D 2671Tensile strength≥7.3MPa158ºC×168hElongation at break≥100%158ºC×168hLongitudinal change-8%~+8%ASTM D 2671FlammabilitySelf-extinguishing in 60 sec.AMS-DTL-23053/4Voltage withstand(Rated voltage 600V)2500V,1min no breakdownUL 224Heat shockNo cracks, no drippingUL 224,250ºC×4hDielectric strength≥15kV/mmIEC 60243Volume resistivity≥1014Ω.cmIEC 60093

Technical Performance of AdhesivePropertyTypical DataTest method/conditionSoftening point95±5ºCASTM E 28Water absorption<0.5%ASTM D 570Peel strength(PE)≥120N/25mmASTM D 1000Peel strength(AI)≥80N/25mmASTM D 1000

Dimensions(3:1) SizeAs supplied ID(mm) DAfter full recovery(mm)Standard packagemm  inchID dWall thickness w1Thickness of adhesive
w2(m/spool,    m/pc)Φ2.43/32≥2.4≤0.800.85±0.150.35±0.08200Φ3.21/8≥3.2≤1.000.95±0.150.35±0.08200Φ4.83/16≥4.8≤1.601.10±0.150.40±0.08100Φ6.41/4≥6.4≤2.201.20±0.150.45±0.08100Φ7.95/16≥7.9≤2.701.35±0.150.50±0.08100Φ9.53/8≥9.5≤3.201.45±0.200.50±0.0850Φ12.71/2≥12.7≤4.201.70±0.200.50±0.0825Φ15.05/8≥15.0≤5.201.80±0.200.55±0.1025Φ19.13/4≥19.1≤6.302.00±0.200.55±0.1025Φ25.41≥25.4≤8.502.10±0.250.55±0.1025Φ30.01-1/4≥30.0≤10.202.20±0.250.60±0.101.22Φ39.01-1/2≥39.0≤13.502.40±0.250.60±0.101.22Φ50.02≥50.0≤17.002.70±0.250.70±0.101.22
 Note:Non-standard dimensions and package are available on request
