24~48 Cores 19" 1u/2u Fiber Optic Rack Mount Patch Panel ODF

HNK Optic Equipment Co., LIMITED
  • Certification：RoHS
  • Connector：Sc, LC, FC, St
  • Port Number：24~48 Cores
  • Usage：Fiber
  • Type：MDF
  • 1u Size：1u(H) X 19”(W) X 300mm(D)

Base Info

  • Model NO.：RPP-AP
  • 2u Size：2u(H) X 19”(W) X 300mm(D)
  • Material：1.2mm Cold Rolled Steel
  • Material Coating：Powder
  • Fiber Cores：24(1u), 48(2u)
  • Transport Package：Foam Board,Bag +Carton
  • Specification：RoHS
  • Trademark：HNK or OEM
  • Origin：Shenzhen, China
  • HS Code：85371090
  • Production Capacity：1000PCS,Month

Description

AdaptorSize(H×W×D )mm1U(H) x 19"(W) x 300mm(D)
2U(H) x 19"(W) x 300mm(D)Multimode Insertion Loss 0.2dB MaximumMaterial 1.2mm Cold Rolled Steel Singlemode Insertion Loss 0.2dB MaximumMaterial CoatingPowderMating durability>500 Mating CyclesHumidity0-90%, non-condensingMultimode Adaptor Wavelength 850 to 1300nmOperating Temperature-10°C to 60°CSinglemode Adaptor Wavelength 1310 to 1550nmStorage Temperature-40°C to 85°CROHS Compliant Yes 24~48 Cores 19" 1u/2u Fiber Optic Rack Mount Patch Panel ODFXXpatch panel TypeWPP=wall mount patch panel, RPP=rack mount patch panelAAProduct IDAP1=1U, AP2=2UBBPort Capacity012=12 Ports, 018=18 Ports, 024=24 Ports, 036=36 PortsCconfigurationE=only patch pane, L=With Adapter Panels,
F=With Adapter Panels and PigtailsDConnector TypeFP,SP,SA,LPEFiber TypeOM1=62.5/125 OM1, OM2=50/125 OM2, OM3=50/125 OM3,
OM4=50/125 OM4, G652D=9/125 G652D, G657A=9/125 G657AFFiber Length05=0.5M, 10=1M, 20=2M
Connector Type CodeCodeConnector CodeConnector CodeConnector CodeConnector FPFC/PCFAFC/APCLPLC/PCLALC/APCSPSC/PCSASC/APCTPST/PCTAST/APCMUMUDNDINMTMTRJE2E2000
Ordering Sample
Part NumberDescription
RPP-AP1-E1U RPP-AP Type Rack Mount Patch Panel without adaptor plate and pigtail.
RPP-AP2-E2U RPP-AP Type Rack Mount Patch Panel without adaptor plate and pigtail.
RPP-AP1-24FSPG652D101U 24 Fibers RPP-AP Type Rack Mount Patch Panel With
Duplex SC/PC SM Adapter and 1M Singlemode G652D SC/PC Pigtail.
