Qszh Automotive Wiring Harness Double-Wall Heat Shrinkable Tube

Union Polymer Material Co., Ltd.

Certification：RoHS, ISO
Color：Black
IP Rating：IP68
Usage：Electric Wire
Material：PE
Type：Heat Shrinkable

Base Info

Model NO.：A1-QSZH
Transport Package：Carton
Specification：4mm-18.3mm
Trademark：UPM
Origin：China
HS Code：3917390000
Production Capacity：2000tons

Description

After shrink(mm)A1-QSZHDiameter(Min.)Diameter(Max.)Wall thickness(Reference)Adhesive W.T.(reference)5.755.75 1.25 1.20 0.60 7.57.5 1.65 1.60 0.80 11.011.0 2.40 2.00 1.00 14.014.0 3.00 2.20 1.20 18.318.3 4.35 2.40 1.40 Cross Reference Tyco-Raychem: QSZH-125 Qszh Automotive Wiring Harness Double-Wall Heat Shrinkable Tube

Qszh Automotive Wiring Harness Double-Wall Heat Shrinkable Tube
