• Model NO.：BS-WS
• Application：Insulators, Electrical Winding Insulation,
• Chemistry：Organic Insulation
• Transport Package：200 M,Roll, 100m,Roll, 50m,Roll, 25m,Roll
• Specification：8mm-40mm ID
• Trademark：EKO
• Origin：Made in China
• HS Code：4602900000
• Production Capacity：150, 000 Meter,Week

Part No.SizeMax. bundle Dia.Packing (L)BS-WS0033.0mm4.0mm200m/rollBS-WS0055.0mm6.0mm100m/rollBS-WS0088.0mm9.0mm100m/rollBS-WS01010.0mm11.0mm100m/rollBS-WS01313.0mm14.0mm50m/rollBS-WS01616.0mm17.0mm50m/rollBS-WS01919.0mm20.0mm25m/rollBS-WS02525.0mm27.0mm25m/rollBS-WS02929.0mm31.0mm25m/rollBS-WS03232.0mm34.0mm25m/rollBS-WS03838.0mm40.0mm25m/rollBS-WS05050.0mm52.0mm25m/roll
Specifications
a.  Highly abrasion resistance
b.  Fireproof, dustproof and noise reduction
c.  Flexibility
d . Easy to install

Application
Most commonly used over wires harnesses, cable assemblies, flat ribbon cables, tubes and hoses to provide a tough, durable protection in automotive, automatic equipment, railways and panel boards.


Feature
1. Easy, cost and labor effective installation
2. More flexible than split convoluted or spiral wrap
3.25% edge overlap
4. Cut and abrasion resistant
5. Halogen free
6. Retains shape and rigidity throughout -50º C to 150º C temperature range
7. Melt temp. 250º C


Technical data

Material	Polyester monofilament and multifilament
Operating range	-50-+150ºC
Melt point	240C+-10C
Flammability	UL94 V0, DIN5510
Certificate	RoHS, Halogen free
Standard color	Black
Cutting tool	Scissors
