Flame-Retardant Thin-Walled Double-Wall Heat Shrinkable Tube for Automobile Wiring Harness

Union Polymer Material Co., Ltd.
  • Certification：RoHS, ISO
  • Color：Black
  • Usage：Electric Wire
  • Material：PE
  • Type：Heat Shrinkable
  • Transport Package：Carton

Base Info

  • Model NO.：S3TA
  • Specification：4mm-18.3mm
  • Trademark：UPM
  • Origin：China
  • HS Code：3917390000
  • Production Capacity：2000tons

Description



After shrink(mm)S3TADiameter(Min.)WT(reference)Diameter(Max.)WT(reference)Adhesive WT(reference)Shrink ratio 4:1     4.0/1.04.0 0.40 1.0 1.0 0.5 6.0/1.56.0 0.60 1.5 1.4 0.7 8.0/2.08.0 0.60 2.0 1.6 0.9 9.0/2.39.0 0.65 2.3 1.8 1.0 11.0/2.411.0 0.65 2.4 2.0 1.1 12.0/3.012.0 0.80 3.0 2.2 1.2 14.0/3.514.0 0.80 3.5 2.3 1.3 16.0/4.016.0 0.80 4.0 2.4 1.4 18.0/4.518.0 0.80 4.5 2.6 1.4 Shrink ratio 3:1     3.2/1.03.2 0.45 1.0 1.0 0.45 4.8/1.64.8 0.50 1.6 1.1 0.5 6.4/2.16.4 0.50 2.1 1.2 0.5 7.9/2.67.9 0.50 2.6 1.3 0.6 9.5/3.29.5 0.50 3.2 1.4 0.6 12.7/4.212.7 0.60 4.2 1.6 0.7 15.0/5.015.0 0.65 5.0 1.8 0.8 19.1/6.019.1 0.70 6.0 1.9 0.8
