Cable Clamp Fitting Distribution Single Top Ties for Insulator
Qingdao Powtech Electronics Co., Ltd.- Certification：CCC, RoHS, ISO, CE
- Color：White
- Fire Rating：High
- Size：Customized
- Material：Aluminium Clad Steel
- Type：Self-Locking Cable Tie
Base Info
- Model NO.：SDB
- Diameter Range：35-150mm
- Length：470-602
- Tensile Strength (Kn)：5
- Transport Package：Wooden Case
- Specification：CE, RoHS, SGS, ISO
- Trademark：OPTELEC
- Origin：China
- HS Code：72202030
- Production Capacity：10000PCS,Month
Description
19.1mm minimum groove radiusSDB-57-2784SDB-73-2784SDB-89-278424.6127.84Green940965990SDB-57-3150SDB-73-3150SDB-89-315027.8631.50Yellow101510401065
Description:
Single line/top ties are intended for securing bare conductors into the top groove of insulators. On vertically-mounted insulators, single line ties/ top ties can normally accommodate line angels of up to 10 depending on insulator orientation.
Material: Aluminum-clad steel with an elastomer pad
Mechanical: Single line ties/top ties will develop unbalanced and lift-off loads equivalent to , or in excess of, a hand tie over covered conductor. When installed with a pad on bare conductor, single line ties/top ties provide superior protection against abrasion and all types of conductor motion. The pad is a resilient cushion at the point of contact between conductor and insulator.
Insulators: Φ57mm (C Neck), Φ73mm (F neck) and Φ89mm (J neck)
Applicable conductor: ACSR, All-Aluminum, Aluminum Alloy and etc ..
Description:
Single line/top ties are intended for securing bare conductors into the top groove of insulators. On vertically-mounted insulators, single line ties/ top ties can normally accommodate line angels of up to 10 depending on insulator orientation.
Material: Aluminum-clad steel with an elastomer pad
Mechanical: Single line ties/top ties will develop unbalanced and lift-off loads equivalent to , or in excess of, a hand tie over covered conductor. When installed with a pad on bare conductor, single line ties/top ties provide superior protection against abrasion and all types of conductor motion. The pad is a resilient cushion at the point of contact between conductor and insulator.
Insulators: Φ57mm (C Neck), Φ73mm (F neck) and Φ89mm (J neck)
Applicable conductor: ACSR, All-Aluminum, Aluminum Alloy and etc ..
